Installation
1
Release handle
A Grasp the lock catch on the front of Lyve Mobile Mount and pull it forward to release the front lock bezel.
B Lower the front lock bezel to open Lyve Mobile Mount.
A
2
Insert device
Insert the device with the ports facing the back of Lyve Mobile Mount. Slide the device toward the back
of the mount.
CAUTION
Lifting hazard. To avoid injury, use
proper lifting techniques when removing
Lyve Mobile Array from its packaging
and installing it in Lyve Mobile Mount.
Lyve Mobile Array weight: 27.8 lb/12.6 kg
B
7
