- Page 1 DO NOT PRINT THIS PAGE Lyve Mobile Rackmout Receiver QSG 100869101B_Lyve Mobile Rackmount Receiver_216mmX279mm_EN_QSG Part Number: 100869101B Folded Size: 215.9 mm W x 279.4 mm H (letter) Trim size: 431.8 mm W x 279.4 mm H Page count: 16 Binding: Saddle stitch...
- Page 2 QUICK START GUIDE...
- Page 3 Rackmount Kit Parts List Back rails (2x) Front rail left Front rail right A M4 screw for 7.1 mm hole (4x) G M4 flat pan head screw (4x) (M4xL10 (6.8,2.5), phillips screw) (M4xL8 phillips screw) B M4 scew for 0.375” hole (4x) H 10-32 pan head screw (4x (M4xL10 (9.1,2.5), phillips screw) (#10-32xL25.4, phillips screw)
- Page 4 B M4 Screw for 0.375” hole (4x) Lyve Mobile Rackmount Receiver CAUTION Removing Lyve Mobile Rackmount Receiver from its packaging TWO-PERSON and carrying the unit must be performed by at least two people. LIFT REQUIRED Receiver weight (empty): 47.52 lb/21.6 kg...
-
Page 5: Rack Assembly
Rack Assembly Attach M4 rack screws to the front rails Your rack may have standard 7.1 mm or .375” openings. M4 screws are provided for both hole dimensions. Insert an M4 screw for 7.1 mm or .375” in the indicated hole on the left front rail and fasten it with an M4 nut. Repeat the process for the right front rail. - Page 6 Attach cage nuts Attach two 10-32 cage nuts to each front rack post. Leave 101.6 mm space between the two nuts on each post. D 10-32 cage nut B A C K 101.6 mm F R O N 804.826 mm 496.685 mm...
- Page 7 Attach the front rails to the front of the rack Position the left front rail on the cage nut on the left front rack post. Insert two 10-32 flat head screws into two stepped washers. Use the screw/washer assemblies to fasten the left front rail to the left front rack post.
- Page 8 Attach the back rails to the back of the rack Position the back rails at the correct height on the rear rack posts. Insert two 10-32 flat head screws into two stepped washers. Use the screw/washer assemblies to fasten the back rails to the rear rack posts. B A C E 10-32 flat head screw F Stepped washer...
- Page 9 Attach the front rails to the back rails Use M4 flat pan head screws to attach the front rails to the back rails. B A C K F R O N G M4 flat pan head screw...
- Page 10 Do not attempt to lift or assemble Lyve Mobile Rackmount Receiver with compatible devices inserted. Position the front face of Lyve Mobile Rackmount Receiver over the cage nuts attached to the left and right front posts. Insert two 10-32 pan head screws into two flat washers. Use the screw/washer assemblies to attach Lyve Mobile Rackmount Receiver to the top cage nuts attached to the left and right front posts.
-
Page 11: Front View
Views Front view Slot B Slot A Back view Power switch Power input – A Power input – B Slot A/Left Slot A/Right Slot B/Left Slot B/Right Host interface CLI – A** Host interface Host interface CLI – B** Host interface module* module* module*... - Page 12 • FC 32Gb, 2-Port SFP+ • iSCSI 25Gb, 4-port 25Gb SFP+ • iSCSI 10GbaseT, 2-Port RJ45 Connect the appropriate fiber optic, Ethernet, or SAS cables to available ports on Lyve Mobile Rackmount Receiver’s back panel. Fiber optic cable Ethernet cable...
-
Page 13: Connect Power
Connect power Insert the zip tie into the slot below the socket. S lo S lo t A / t A / L e f L e f S lo S lo t A / t A / R ig R ig C L I C L I... - Page 14 Connect compatible devices Insert compatible devices into slot A or B on Lyve Mobile Rackmount Receiver. Slide device in until it’s fully inserted and firmly connected to Lyve Mobile Rackmount Receiver’s data and power. Close latches.
-
Page 15: Turn On Power
C L I When managing mounted devices using the Lyve Pilot SC app, make certain to connect Lyve Mobile Rackmount Receiver to the same network as the host device. The Lyve Pilot SC app is available for S l o... - Page 16 Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Beginning on January 1, 2018, Seagate products must comply with the “Marking of presence” requirements in Section 5 of CNS 15663. This product is Taiwan RoHS compliant.
- Page 17 © 2020 Seagate Technology LLC. All rights reserved. Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Lyve is either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
