Malvern - 3 Drawer 3 Door Robe

Assembly Instructions -

Dimensions

Width - 119cm

Depth - 49.5cm

Height - 180cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

395/5152

380/4629

MADE IN

BRITAIN

Issue 1 - 11/05/15

Need help?

Do you have a question about the Malvern 395/5152 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Malvern 395/5152

Page 1 Malvern - 3 Drawer 3 Door Robe Assembly Instructions - 395/5152 Please keep for future reference 380/4629 Dimensions Width - 119cm Depth - 49.5cm MADE IN Height - 180cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 11/05/15...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 79kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (DF4047) (1187 x 492mm) Base (DF4048) (1179 x 474mm) Left Side Right Side Divider (DF3950)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 2 top drawer fronts Screw 2 metal dowels into each of the top drawer fronts Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the top drawer sides and down into the groove in the top drawer front Step 5 Fit the top drawer back Fit the top drawer back between the top drawer sides Make sure that the...
Page 7 Assembly Instructions Step 8 Prepare the bottom drawer front Screw 2 metal dowels into the bottom drawer front Step 9 Prepare the bottom drawer sides Insert a small locking into the hole shown on the bottom left drawer side and the bottom right drawer side Step 10 Attach the bottom...
Page 8 Assembly Instructions Step 11 Fit the drawer base Slide the drawer base down the grooves in the bottom drawer sides and down into the groove in the bottom drawer front Step 12 Fit the bottom drawer back Fit the bottom drawer back between the bottom drawer sides...
Page 9 Assembly Instructions Step 15 Runners must be Fit runners to the 2 pushed up against top drawers the drawer front Fit runner , marked with ‘R’, to the bottom edge of the top right drawer side , as shown, making sure that it is pushed up against the back of the top drawer front...
Page 10 Assembly Instructions Step 17 screw screw screw Prepare the divider Fit 3 runners the divider The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
Page 11 Assembly Instructions Step 18 Turn the Finish preparing the divider over divider Turn the divider over Finished To fit the rail holder front edge screw through the top hole with screw into the mark hole drilled in the divider . Make sure that it is fitted straight, in line with the panel edges and then fit...
Page 12 Assembly Instructions Step 21 screw screw screw Prepare the left side Fit 3 runners the left side The 1st screw uses the 1st hole in from the front of the runner. Finished The 2nd and 3rd screws front edge use the holes that line up with the other panel holes.
Page 13 Assembly Instructions Step 22 Prepare the cross rail Finished front edge Tap 2 wooden dowels into the cross rail Insert 2 large locking nuts into the cross rail Step 23 Fit the cross rail Push the cross rail Finished onto the divider front edge Use a screwdriver to tighten the large locking...
Page 14 Assembly Instructions Step 25 Prepare the small shelf Tap 4 wooden dowels into the small shelf Insert 4 large locking nuts into the small Finished front edge shelf Unfinished back edge Step 26 Fit the small shelf to the divider Push the small shelf onto the divider Use a screwdriver to...
Page 15 Assembly Instructions Step 27 Prepare the right side Fit 3 hinge plates onto the right side , making sure that the slot is facing towards the finished front edge. To fit the rail holder screw through the top hole with screw into the mark hole drilled in the right side Make sure that it is fitted...
Page 16 Assembly Instructions Step 29 Fit the base Attach the base the left side , right side and divider using 6 screws Step 30 Prepare the top Screw 6 metal dowels into the top Finished front edge...
Page 17 Assembly Instructions Step 31 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the left side , right side and divider Note: To make it easier to fit the top panel, place polystyrene blocks from the packaging underneath the side and divider...
Page 18 Assembly Instructions Step 33 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x:x equals y:y.
Page 19 Assembly Instructions Step 34 Fit the drawers Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panel and push the drawers into position. Side panel Drawer d r a T o p d r a T o p...
Page 20 Assembly Instructions Step 36 Prepare the 3 doors Push fit 3 hinges into each of the 3 doors Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees with the edge of the door.
Page 21 Assembly Instructions Step 37 Fit doors and handles Note: The easiest way to attach each door 20 21 and . is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
Page 22 Assembly Instructions Step 38 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 23 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 24 ALR3205...

This manual is also suitable for:

Malvern 380/4629
