Malvern - 1 Drawer 2 Door Robe
Assembly Instructions -
Dimensions
Width - 79.5cm
Depth - 49.5cm
Height - 180cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
390/9641
392/1131
MADE IN
BRITAIN
Issue 1 - 11/05/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Malvern 390/9641
Summary of Contents for Argos Malvern 390/9641
- Page 1 Malvern - 1 Drawer 2 Door Robe Assembly Instructions - 390/9641 Please keep for future reference 392/1131 Dimensions Width - 79.5cm Depth - 49.5cm MADE IN Height - 180cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 11/05/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 52kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Shelf (DF103) (DF107) (795 x 492mm) (753 x 473mm) Cross Rail (DF106) (753 x 78mm) Base...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Runners must be Fit the runners pushed up against the drawer front Fit a runner marked with ‘R’, to the bottom edge of the right drawer side , as shown, making sure that it is pushed up against the back of the drawer front .
- Page 8 Assembly Instructions Step 10 screw screw screw Prepare the left side Fit a runner the left side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 9 Assembly Instructions Step 11 screw screw screw Prepare the right side Fit a runner the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 10 Assembly Instructions Step 12 Fit the shelf to the right side Push the shelf onto the right side Use a screwdriver to Finished tighten the 2 large front edge locking nuts fitted to the shelf Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 11 Assembly Instructions Step 15 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 3 large locking nuts fitted to the shelf and the cross rail Step 16 Fit the base Attach the base the left side and right side...
- Page 12 Assembly Instructions Step 18 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the left side and right side Finished front edge Step 19 Fit the feet Fit the feet to the base using screws...
- Page 13 Assembly Instructions Step 20 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 14 Assembly Instructions Step 22 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 23 Prepare the 2 doors Push fit 3 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 15 Assembly Instructions Step 24 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 16 Assembly Instructions Step 25 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 17 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR3202...
