Malvern - 5 Drawer Chest
Assembly Instructions -
Dimensions
Width - 79.5cm
Depth - 39.5cm
Height - 109cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
391/9538
395/6326
MADE IN
BRITAIN
Issue 1 - 11/05/15
Advertisement
Table of Contents
Related Manuals for Argos Malvern 391/9538
Summary of Contents for Argos Malvern 391/9538
- Page 1 Malvern - 5 Drawer Chest Assembly Instructions - 391/9538 Please keep for future reference 395/6326 Dimensions Width - 79.5cm Depth - 39.5cm MADE IN Height - 109cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 11/05/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 39kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top Left Drawer Side (W370-124LH) (370 x 124mm) (DF95) (795 x 392mm) Top Right Drawer Side (W370-124RH)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 4 top drawer fronts Screw 2 metal dowels into each of the top drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the top drawer sides and down into the groove in the top drawer front Step 5 Fit the top drawer back Fit the top drawer back between the top drawer sides Make sure that the...
- Page 7 Assembly Instructions Step 8 Prepare the bottom drawer front Screw 2 metal dowels into the bottom drawer front Step 9 Prepare the bottom drawer sides Insert a small locking into the hole shown on the bottom left drawer side and the bottom right drawer side Step 10 Attach the bottom...
- Page 8 Assembly Instructions Step 11 Fit the drawer base Slide the drawer base down the grooves in the bottom drawer sides and down into the groove in the bottom drawer front Step 12 Fit the bottom drawer back Fit the bottom drawer back between the bottom drawer sides...
-
Page 9: Bottom Drawer Sides
Assembly Instructions Step 15 Runners must be pushed up against the drawer front Fit runners to the 4 top drawers Fit runner , marked with ‘R’, to the bottom edge of the top right drawer side , as shown, making sure that it is pushed up against the back of the top drawer front... -
Page 10: Step 17
Assembly Instructions Step 17 screw screw screw Prepare the left side Fit 5 runners the left side The 1st screw uses the 1st hole in from the Finished front of the runner. front edge The 2nd and 3rd screws use the holes that line up with the other panel holes. -
Page 11: Step 18
Assembly Instructions Step 18 screw screw screw Prepare the right side Fit 5 runners the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes. - Page 12 Assembly Instructions Step 19 Prepare the rail Tap 2 wooden dowels into the rail Finished Insert 2 large locking front edge nuts into the rail Step 20 Fit the rail to the right side Push the rail onto the right side Use a screwdriver to tighten the large locking fitted to the rail...
- Page 13 Assembly Instructions Step 22 Fit the base Attach the base the left side and right side using 4 screws Finished front edge Step 23 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 24 Fit the top Push the top onto the assembly.
- Page 14 Assembly Instructions Step 25 Fit the feet Fit the feet to the base using screws Step 26 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that...
- Page 15 Assembly Instructions Step 27 Fit the drawers Side panel Drawer Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position. d r a T o p d r a T o p...
- Page 16 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3206...
