Summary of Contents for Argos 395/8953
- Page 1 BASIC CABINET DRAWERS AND SHELVES 395/8953 30cm 28cm 150cm Issue 1- 30/03/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, recommend the use pages 2 and 3..
- Page 3 Top panel x 1 Upper left side panel x 1 Upper right side panel x 1 Lower left side panel x 1 (30(w)cm x 28(d)cm) (57(w)cm x 28(d)cm) (57(w)cm x 28(d)cm) (89.5(w)cm x 28(d)cm) Lower right side panel x 1 Shelf panel x 1 Shelf panel x 2 Cross bar x 2...
- Page 4 35mm Male camlock x 28 15mm Female camlock x 20 30mm Wooden dowel x 4 45mm Screw x 4 30mm Screw x 8 12mm Female camlock x 8 12mm Screw x 18 12mm Screw x 22 Knob x 3 16mm Bolt x 3 Drawer limiter x 4 12mm Screw x 1 Safety strap x 1...
- Page 5 Using Camlocks Connect the male Push the male camlock camlock as directed in into the entry hole. the assembly instructions using a screwdriver. Turn the female camlock lnsert the female clockwise with a camlock as shown in the screwdriver. instructions You should feel a click Note: ensure that the when the camlock is...
- Page 6 Insert 16 x male camlock into top panel , shelf panel , 2 x drawer front panel as shown. Insert 4 x male camlock into upper left side panel and upper right side panel as shown. Insert 8 x male camlock into lower left side panel and lower right...
- Page 7 Attach shelf panel upper right side panel using 2 x 15mm female camlock as shown. Tighten female camlocks with a screwdriver. Please refer to the “Using Camlocks” section at the front of this instruction for further assistance. Attach upper left side panel to shelf panel using 2 x 15mm female...
- Page 8 Attach 1 x shelf panel to lower right side panel using 2 x 15mm female camlock shown. Tighten female camlocks with a screwdriver. Insert 2 x wooden dowel into 2 x cross bar and attach them to the lower right side panel using 2 x 15mm female camlock as shown.
- Page 9 Attach upper back panel and lower back panel to the assembled part using 22 x 12mm screw as shown. Attach 1 x drawer left side panel and 1 x drawer right side panel 1 x drawer back panel using 4 x 30mm screw as shown.
- Page 10 4 x female camlocks and paste 4 x 20mm sticker over the holes of them as shown. If you need help or have damaged or missing parts, call the Customer Helpline: 0345 640 0800 Argos LTD. 489-499 Avebury boulevard, Central Milton Keynes, MK9 2NW...
