Argos 392/4839 Assembly Instructions

Colourmatch gemini bar stool

Download this manual

Colourmatch Gemini Bar Stool

Assembly Instructions -

Dimensions

Width - 52cm

Depth - 43cm

Height - 99.5cm

Important

- Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline:

Argos = 0345 640 0800

Please keep for future reference

392/4839

414/8793

414/6489

391/9655

Issue 1 - 09/04/15

Need help?

Do you have a question about the 392/4839 and is the answer not in the manual?

Page 1 Width - 52cm Depth - 43cm Height - 99.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 09/04/15...
Page 2: Handy Hints
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce the components and tools listed on or put weight on the product, this likelihood of the following pages.
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below 1 Seat (52 x 42 x 29cm) 3 Upper leg 4 Lower leg 2 Stretcher (72 x 52.5 x 3cm)
Page 4 Assembly Instructions Step 1 Attaching legs Position the upper leg and lower leg shown. Align holes and fix using bolt & nut Important: Tighten bolt and nut using allen key spanner but do not fully tighten at this stage. Step 2 Attaching stretcher Position the stretcher between the legs as...
Page 5 . Tighten the bolts using allen key Important: Do not over tighten bolt Carefully turn over the bar stool. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800...
