10 Tier Rolling Shoe Rack
Assembly Instructions -
390/9665
Please keep for future reference
Dimensions
Width - 73cm
Depth - 22.5cm
Height - 163.5cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 2 - 27/08/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 390/9665
Summary of Contents for Argos 390/9665
- Page 1 10 Tier Rolling Shoe Rack Assembly Instructions - 390/9665 Please keep for future reference Dimensions Width - 73cm Depth - 22.5cm Height - 163.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed on or put weight on the product, the likelihood of the following pages.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Lower Side Frame x 2 Upper Side Frame x 2 710 mm Black Coated Steel Tube x 20 694 mm Black Coated Steel Tube x 2 Components - Fittings Please check you have all the fittings listed below... - Page 4 Assembly Instructions Step 1 Connect 710 mm Black Coated Steel Tube with Upper Side Frame using Screw. Connect 694 mm Black Coated Steel Tube with Upper Side Frame using 28mm Screw. See fig 1. Now finished the upper part of shoe rack. fig 1.
- Page 5 Assembly Instructions Step 3 Connect the uppper part of shoe rack with lower part of shoe rack together. Note: It would be useful to ask someone to help you at this stage. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
