  • Page 1 A+ Server ASG- 1014S-ACR12N4H USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found at our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Chassis Rear ........................11 1.5 Motherboard Layout ......................12 Quick Reference Table ......................13 Chapter 2 Server Installation 2.1 Overview ..........................15 2.2 Preparing for Setup ......................15 Choosing a Setup Location ....................15...
  • Page 5 A+ Server ASG -1014S-ACR12N4H User's Manual DIMM Removal .........................36 PCI Expansion Card Installation ..................37 SAS Backplane Information ....................38 Motherboard Battery ......................39 3.4 Chassis Components ......................40 Storage Drives ........................40 NVMe Drive Carrier Indicators ..................42 Hot-Swap for NVMe Drives ...................42 Checking the Temperature of an NVMe Drive ..............43 Installing an M.2 Solid State Drive ..................44 System Fans ........................46 Checking the Server Air Flow ..................47...
  • Page 6 Preface 6.6 Security ..........................96 6.7 Boot ..........................100 6.8 Save & Exit ........................102 Appendix A Standardized Warning Statements for AC Systems Appendix B UEFI BIOS Recovery Appendix C System Specifications...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    A+ Server ASG -1014S-ACR12N4H User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the ASG -1014S-ACR12N4H storage server, which is based on the H12SSW-NTR motherboard and the CSE-802TS-R804WBP chassis. The table below lists the main parts that are included with the system. Main Parts List Description Part Number...

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the ASG -1014S-ACR12N4H. Please refer to Appendix C for additional specifications. System Features Motherboard H12SSW-NTR Chassis CSE-802TS-R804WBP Single AMD EPYC™ 7002/7003 Series Processor Socket Type Memory Up to 4TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS/NVDIMM memory in sixteen slots...

  • Page 10: Server Chassis Features

    A+ Server ASG -1014S-ACR12N4H User's Manual 1.4 Server Chassis Features Control Panel There are two buttons located on the front of the chassis: a power on/off button and a reset button. In addition there are five LEDs. The locations of these buttons and LEDs on the control panel are described below.

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The CSE-802TS-R804WBP is a 1U chassis See the illustration below for the features included on the front of the chassis. Figure 1-2. Front Chassis View Front Chassis Features Item Feature Description Control Panel Control panel (see previous page for details) These levers lock the internal drive drawer to the chassis.

  • Page 12: Motherboard Layout

    A+ Server ASG -1014S-ACR12N4H User's Manual 1.5 Motherboard Layout Below is a layout of the H12SSW-NTR with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. USB 2/3 LAN 2 COM1...

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting UID SW Unit ID switch (push-button toggle switch ON/OFF) JBT1 Clear CMOS Open (Normal) JWD1 Watch Dog control Pins 1-2 (Reset) JPL1 LAN Enable/Disable Pins 1-2 (Enabled) Description Status LED1 UID LED Blue: UID Activated LED9...
  • Page 14 A+ Server ASG -1014S-ACR12N4H User's Manual H12SSW-NTR IPMI LAN RJ45 AMD SP3 Rev. 1.01 Rear USB 3.0 10Gb LAN 10Gb LAN RJ45 RJ45 Rear SXB1 SXB2 USB 3.0 COM1 RX 0-7 RX 15-8 ASM1042 ASM1042 TX 0-7 TX 15-8 USB controller USB controller CPU P3 [10] TX 0-15...

  • Page 15: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 16: Rack Precautions

    A+ Server ASG -1014S-ACR12N4H User's Manual Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.

  • Page 17: Mechanical Loading

    Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 18: Installing The Chassis

    A+ Server ASG -1014S-ACR12N4H User's Manual 2.3 Installing the Chassis This section provides information on installing the chassis into a rack unit with the rails provided. The Toolless Rail System The SC802 chassis uses a toolless rail system that does not need -- as the name implies -- any hand tool to mount the rails and chassis into the server rack.
  • Page 19 Chapter 2: Server Installation Insert the top hook first, push it downwards to allow its hook to rest and engage the selected mounting hole. When the top hook is rested and engaged into place, push the bottom lock into the lower hole until it clicks and snaps into place Insert until bottom lock snaps into place.
  • Page 20 A+ Server ASG -1014S-ACR12N4H User's Manual Slide rail mounted equipment is not to be used as a shelf or a work space. The illustration below shows both the left and right rails mounted on a rack, ready to accept the server chassis. Right Rail Left Rail Figure 2-3.

  • Page 21: Sliding The Chassis Onto The Rack Rails

    Chapter 2: Server Installation Sliding the Chassis onto the Rack Rails Installing the Chassis into a Rack 1. Align the chassis rails with the front of the rack rails. 2. Slide the chassis rails into the rack rails, letting it rest on to the inner rail lips, while keeping the pressure even on both sides.
  • Page 22 A+ Server ASG -1014S-ACR12N4H User's Manual The chassis can then be secured to the rack by two thumb screws located on the left and right of the front side of the chassis. Figure 2-5. Securing the Chassis to the Rack Removing the Rails Removing a rail is basically just the reverse of the installation procedure.

  • Page 23: Chapter 3 Maintenance And Component Installation

    A+ Server ASG -1014S-ACR12N4H User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 24: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The system is fully accessible by loosening the two front thumbscrews and pulling out the drive drawer completely. Lever Loosen Thumbscrews Lever then pull out levers Pull Out Figure 3-1. Removing the Chassis Cover Removing the Chassis Cover 1.

  • Page 25: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the Processor and Heatsink 1. Unscrew the screws holding down Force Frame in the sequence of 3-2-1. The screws are numbered on the force frame next to each screw hole.
  • Page 26 Chapter 3: Maintenance and Component Installation 2. The spring-loaded force frame will raise up after the last screw securing it (#1) is removed. Gently allow it to lift up to its stopping position. 3. Lift the rail frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the rail frame, lift it to a position so you can do the next step of removing the external cap.
  • Page 27 A+ Server ASG -1014S-ACR12N4H User's Manual 4. Remove the external cap from the Rail Frame by pulling it upwards through the rail guides on the rail frame. External Cap PnP Cover Cap 5. The CPU package is shipped from the factory with the green (7xx2) or gray (7xx3) carrier frame pre-assembled.
  • Page 28 Chapter 3: Maintenance and Component Installation Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the rail frame plate.
  • Page 29 A+ Server ASG -1014S-ACR12N4H User's Manual 8. Gently lower the rail frame down onto the socket until the latches on the rail frame engage with the socket housing and it rests in place. DO NOT force it into place! 9. Gently lower the force frame down onto the rail frame and hold it in place until it is seated in the Socket housing.
  • Page 30 Chapter 3: Maintenance and Component Installation 10. Place and re-screw the screws in the reverse order to the way you removed them (holes 1-2-3 in order). When finished, the force frame will be secure over both the rail frame and CPU package. 11.
  • Page 31 A+ Server ASG -1014S-ACR12N4H User's Manual 12. Using a diagonal pattern, tighten the four screws down on the heatsink in a clockwise fashion till it is secure. The heatsink will now be secured and you have finished installing the processor and heatsink onto the motherboard. Repeat this procedure for any remaining CPU sockets on the motherboard.
  • Page 32 Chapter 3: Maintenance and Component Installation Un-installing the Processor and Heatsink 1. Remove the heatsink attached to the top of the CPU package by reversing the installation procedure. 2. Clean the Thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing.

  • Page 33: Memory Support And Installation

    A+ Server ASG -1014S-ACR12N4H User's Manual Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The H12SSW-NTR supports up to 4TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS memory in sixteen slots.

  • Page 34: Dimm Module Population

    Chapter 3: Maintenance and Component Installation DIMM Module Population There is no specific order or sequence required when installing memory modules. However do keep the following in mind: • Always use DDR4 DIMM modules of the same type, size and speed. •...
  • Page 35 A+ Server ASG -1014S-ACR12N4H User's Manual Processors and their Corresponding Memory Modules Channel CPU# 1 DIMM (Not Recommended) CPU1 2 DIMMs (Not Recommended) CPU1 4 DIMMs CPU1 6 DIMMs Unbanalced and not recommended. 8 DIMMs CPU1 16 DIMMs CPU1 *Note: To achieve optimal memory performance, the minimum recommended is at least one DIMM for each channel pair in the system (e.g., A, C, E, G).

  • Page 36: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Insert the desired number of DIMMs into the memory slots, there is no specific sequence or order required Receptive 2. Push the release tabs outwards on both Point ends of the DIMM slot to unlock it. 3.

  • Page 37: Pci Expansion Card Installation

    A+ Server ASG -1014S-ACR12N4H User's Manual PCI Expansion Card Installation The chassis supports two full height and one low profile PCIe expansion cards. Installing an Expansion Card 1. Power down the system as described in Section 3.1 and remove the rear cover. 2.

  • Page 38: Sas Backplane Information

    Chapter 3: Maintenance and Component Installation SAS Backplane Information The ASG -1014S-ACR12N4H comes with three backplanes for four 3.5" SATA3 or SAS3 HDD drives (BPN-SAS3-802A-3). These backplanes have their own two LED indicators for activity and status as shown in the figure and table below. Note: Two of the four LEDs on the backplanes are currently not used for this server and are not active.

  • Page 39: Motherboard Battery

    A+ Server ASG -1014S-ACR12N4H User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 40: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.4 Chassis Components Storage Drives The SC802 family chassis supports twelve 3.5" storage drives in toolless drive carriers to simplify their removal from the chassis. These carriers also help promote proper airflow. The drives rest on metal brackets that runs the full width of the chassis. They attach to the system by means of three small, horizontal backplanes that supports four 3.5"...
  • Page 41 A+ Server ASG -1014S-ACR12N4H User's Manual Backplanes Latch Pull handle 3.5" HDD Figure 3-7. Adding and Replacing Hard Drives...

  • Page 42: Nvme Drive Carrier Indicators

    Indicates NVMe drive is safe to remove. Amber Blinking at 1 Hz Attention state—do not remove NVMe device. Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at https://www. supermicro.com/en/products/storage/superstorage/drives.

  • Page 43: Checking The Temperature Of An Nvme Drive

    A+ Server ASG -1014S-ACR12N4H User's Manual Figure 3-4. IPMI Screenshot Replacing the Drive 1. Insert the replacement drive. 2. System > Storage Monitoring > Physical View 3. Select Slot and click Insert. The drive Status LED indicator flashes red, then turns off. The Activity LED turns blue..

  • Page 44: Installing An M.2 Solid State Drive

    Chapter 3: Maintenance and Component Installation Installing an M.2 Solid State Drive Note: There are some thermal limitations with M.2 drives. Please contact Supermicro Support before installing an M.2 device. The motherboard can accommodate an M.2 solid state drive (SSD). The M.2 socket supports NVMe PCIe 4.0 x2 cards in the 2280 or 22110 form factors.
  • Page 45 A+ Server ASG -1014S-ACR12N4H User's Manual Installing an M.2 2280 Device 1. Power down the system as described in Section 3.1 and then remove the top chassis cover as described in Section 3.2. 2. To loosen the M.2 plastic standoff on the motherboard, lift up its top square latch, and use gentle force to pull it out of the hole.

  • Page 46: System Fans

    Chapter 3: Maintenance and Component Installation System Fans Six fans provide cooling for the chassis. Figure 3-6. System Fans (lifted out from chassis) Replacing a System Fan 1. If necessary, open the top rear cover of the chassis while the system is running to locate the position of the failed fan.

  • Page 47: Checking The Server Air Flow

    Overheat Temperature Setting Some backplanes allow the overheat temperature to be set at 45, 50, or 55 by changing a jumper setting. For more information, consult the backplane user manual at www.supermicro. com. (Click Support, then the Manuals link.) Responses If the server overheats: 1.

  • Page 48: Power Supply

    Failed power supplies should be replaced as soon as convenient. The power supply modules are hot-swappable, meaning they can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v as needed by the system.

  • Page 49: Power Supply Leds

    A+ Server ASG -1014S-ACR12N4H User's Manual Power Supply LEDs On the rear of the power supply module, an LED displays the status. • Solid Green: When illuminated, indicates that the power supply is on. • Solid Amber: When illuminated, indicates the power supply is plugged in and turned off, or the system is off but in an abnormal state.

  • Page 50: Chapter 4 Motherboard Connections

    A+ Server ASG -1014S-ACR12N4H User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 51 Chapter 4: Motherboard Connections 12V 8-pin Auxilliary Power Connector (JPWR1) JPWR1 is an 8-pin ATX power input to provide auxiliary power to the processor. Refer to the table below for pin definitions. 12V 8-pin Power Connector Pin Definitions Pins Definition 1 through 4 Ground 5 through 8...

  • Page 52: Headers And Connectors

    A+ Server ASG -1014S-ACR12N4H User's Manual 4.2 Headers and Connectors Onboard Fan Headers (FAN1~FAN6) There are six fan headers on the motherboard. These are 4-pin fan headers; pins 1-3 are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled by Thermal Management (via Hardware Monitoring) in the BMC.
  • Page 53 It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Please go to the following link for more information on TPM: http://www.supermicro.com/ manuals/other/TPM.pdf. Trusted Platform Module Header...
  • Page 54 A+ Server ASG -1014S-ACR12N4H User's Manual USB Ports (USB0~USB4, USB6/7) There are a total of seven USB ports supported on the motherboard. Four are located on the back panel , USB0/1, and USB2/3 via ASM1042 (both are USB 3.0 compliant). There are also three ports located on the motherboard, two are on one header, USB6/7 (3.0) and and the remaining one is on a 3.0 "Type A"...
  • Page 55 Chapter 4: Motherboard Connections Chassis Intrusion (JL1) A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to the header to inform you when the chassis is opened. Chassis Intrusion Pin Definitions Pins Definition Ground...

  • Page 56: Control Panel

    A+ Server ASG -1014S-ACR12N4H User's Manual Control Panel JF1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 57 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com. UID LED Pin Definitions (JF1)
  • Page 58 A+ Server ASG -1014S-ACR12N4H User's Manual HDD LED/UID Switch The HDD LED/UID Switch connection is located on pins 13 and 14 of JF1. Attach a cable to Pin 14 to show hard drive activity status. Attach a cable to Pin 13 to use UID switch. Refer to the table below for pin definitions.

  • Page 59: Rear I/O Ports

    Chapter 4: Motherboard Connections 4.3 Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description Description COM Port USB 2 (3.0) VGA Port IPMI LAN Port...
  • Page 60 See page 36 for the front panel UID LED header location on JF1. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com...

  • Page 61: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 62 A+ Server ASG -1014S-ACR12N4H User's Manual Watch Dog (JWD1) JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs.

  • Page 63: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN Port LEDs The motherboard's Ethernet ports has two LED indicators. The Activity LED is green and indicates connection and activity. The Link LED may be green, orange/amber, or off to indicate the speed of the connection. Refer to the tables below for more information. H12SSW-NTR Link LED, Connection Link, Speed Indicator...

  • Page 64: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 65 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 66: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 67: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 68: Chapter 6 Uefi Bios

    A+ Server ASG -1014S-ACR12N4H User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the H12SSW-NTR motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 69: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2015 after RTC reset. Supermicro H12SSW-NTR BIOS Version This item displays the version of the BIOS ROM used in the system.
  • Page 70 A+ Server ASG -1014S-ACR12N4H User's Manual Build Date This item displays the date when the version of the BIOS ROM used in the system was built. CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This feature displays the total system memory detected.

  • Page 71: Advanced

    Chapter 6: UEFI BIOS 6.3 Advanced Use the arrow keys to select a top item and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 72 A+ Server ASG -1014S-ACR12N4H User's Manual Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are On and Off. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 73 Chapter 6: UEFI BIOS Trusted Computing  Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security.
  • Page 74 A+ Server ASG -1014S-ACR12N4H User's Manual Super IO Configuration The following Super IO information will display: • Super IO Chip AST2500 Serial Port 1 Configuration Serial Port Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled.
  • Page 75 Chapter 6: UEFI BIOS *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support.
  • Page 76 A+ Server ASG -1014S-ACR12N4H User's Manual Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 77 Chapter 6: UEFI BIOS Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 78 A+ Server ASG -1014S-ACR12N4H User's Manual Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 79 Chapter 6: UEFI BIOS Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII character set. Select VT100+ to add color and function key support. Select ANSI to use the extended ASCII character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 80 A+ Server ASG -1014S-ACR12N4H User's Manual Core Performance Boost This setting is used to configure for Core Performance Boost. Options include Disabled and Auto. Global C-state Control This setting is used to configure for Global C-state Control. Options include Disabled, Enabled, and Auto.
  • Page 81 Chapter 6: UEFI BIOS • L2 Data Cache (Size/Method) • L3 Cache per Scoket (Size/Method) NB Configuration  North Bridge Configuration Determinism Control Use this setting to configure the Determinism Slider. The options include Manual and Auto. cTDP Control Use this setting to configure the cTDP Control. The options include Manual and Auto. IOMMU Use this setting to enable/disable IOMMU.
  • Page 82 A+ Server ASG -1014S-ACR12N4H User's Manual Memory Interleaving Size This setting controls the memory interleaving size. This determines the starting address of the interleave (bit 8, 9, 10 or 11). The options are 256 Bytes, 512 Bytes, 1 KB, 2 KB or Auto. Chipset Interleaving This setting controls interleave memory blocks across the DRAM chip for node 0.
  • Page 83 Chapter 6: UEFI BIOS PCIe ARI Support Use this setting to enable/disable Alternative Routing-ID Interpretation (ARI). The options are Disabled, Enabled and Auto. PCIe Spread Spectrum Use this setting to Disable or Enable PCIe Spread Spectrum for your system. Target Link Speed If supported by hardware and set to Force to x.S GT/S (x being a value of 2.5, 5.0 or 8.0) for Downstream Ports, this sets an upper limit on Link Operational Speed by restricting the values advertised by the UPstream component in its training sequences.
  • Page 84 A+ Server ASG -1014S-ACR12N4H User's Manual Onboard LAN1 Option ROM Use this setting to select which option ROM is to be loaded for onboard LAN1 on the system. Options include Disabled, Legacy and EFI. Onboard LAN2 Option ROM Use this setting to select which firmware function is to be loaded for onboard LAN2 on the system.
  • Page 85 Chapter 6: UEFI BIOS USB Configuration Legacy USB Support Select Enabled to support onboard legacy USB devices. Select Auto to disable legacy support if there are no legacy USB devices present. Select Disable to have all USB devices available for EFI applications only. The options are Enabled, Disabled and Auto. XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Extensible Host Controller Interface) hand-off.
  • Page 86 A+ Server ASG -1014S-ACR12N4H User's Manual ASMedia SATA Information This section displays information on the detected ASMedia SATA devices: • SATA Mode SATA Configuration SATA Enable This item enables or disables the onboard SATA controller supported by the Intel PCH chip. The options are Enabled and Disabled.
  • Page 87 Chapter 6: UEFI BIOS Enter Configuration Menu  Create New VLAN VLAN ID This option is an input field used to enter a unique numeric VLAN ID. The valid range is from 0~4096. Priority This option is an input field used to enter a unique numeric VLAN 802.1Q priority. The valid range is from 0~7.
  • Page 88 A+ Server ASG -1014S-ACR12N4H User's Manual Local Gateway This item sets the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1). Local DNS This item sets the address for the local DNS servers for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1).
  • Page 89 Chapter 6: UEFI BIOS  Change Attempt Order TLS Authentication Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification Using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.
  • Page 90 A+ Server ASG -1014S-ACR12N4H User's Manual Create raw This feature allows the user to create a raw RAM disk from all available memory modules in the system. When you select this submenu and press <Enter>, the following items will display: •...

  • Page 91: Ipmi

    Chapter 6: UEFI BIOS 6.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system.
  • Page 92 A+ Server ASG -1014S-ACR12N4H User's Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 93 Chapter 6: UEFI BIOS Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form. Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255.

  • Page 94: Event Logs

    A+ Server ASG -1014S-ACR12N4H User's Manual 6.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during...
  • Page 95 Chapter 6: UEFI BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.
  • Page 96 A+ Server ASG -1014S-ACR12N4H User's Manual 6.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well. Password Check Select Setup for the system to check for a password at Setup.
  • Page 97 Chapter 6: UEFI BIOS This option allows you specify when the Platform Key (PK) is enrolled. When enabled, the System Mode is user deployed, and the CSM function is disabled. Options include Disabled and Enabled . Secure Boot Mode Use this item to select the secure boot mode. The options are Standard and Custom. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot.
  • Page 98 A+ Server ASG -1014S-ACR12N4H User's Manual Restore DB defaults Select and press Yes to restore the DB variables to factory defaults. The options are Yes and No. Platform Key (PK) This feature allows the user to configure the settings of the platform keys. Set New Key Select Yes to load the new platform keys (PK) from the manufacturer's defaults.
  • Page 99 Chapter 6: UEFI BIOS Authorized TimeStamps Set New Key Select Yes to load the DBT from the manufacturer's defaults. Select No to load the DBT from a file. The options are Yes and No. Append Key Select Yes to add the DBT from the manufacturer's defaults list to the existing DBT. Select No to load the DBT from a file.
  • Page 100 A+ Server ASG -1014S-ACR12N4H User's Manual 6.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are LEGACY, UEFI, and DUAL. The default setting is DUAL. Legacy to EFI Support This option Enables or Disables the system to boot to an EFI OS after the boot failed from the legacy boot order.
  • Page 101 Chapter 6: UEFI BIOS  UEFI Application Boot Priorities This feature allows the user to specify which UEFI devices are boot devices. • UEFI Boot Order #1  NETWORK Drive BBS Priorities This feature allows the user to specify which UEFI network drive devices are boot devices.
  • Page 102 A+ Server ASG -1014S-ACR12N4H User's Manual 6.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 103 Chapter 6: UEFI BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance.
  • Page 104 Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 105 Appendix A: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 106 A+ Server ASG -1014S-ACR12N4H User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 107 Appendix A: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 108 A+ Server ASG -1014S-ACR12N4H User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 109 Appendix A: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 110 A+ Server ASG -1014S-ACR12N4H User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
  • Page 111 Appendix A: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 112 A+ Server ASG -1014S-ACR12N4H User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 113 Appendix A: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 114 A+ Server ASG -1014S-ACR12N4H User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가...
  • Page 115 Appendix A: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 116 A+ Server ASG -1014S-ACR12N4H User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 117 Appendix A: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 118 A+ Server ASG -1014S-ACR12N4H User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 119 Appendix A: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 120 A+ Server ASG -1014S-ACR12N4H User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 121 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 122 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 123 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
  • Page 124 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 125 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 126 A+ Server ASG -1014S-ACR12N4H User's Manual Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 127 Appendix D: UEFI BIOS Recovery 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell].
  • Page 128 A+ Server ASG -1014S-ACR12N4H User's Manual 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system. 10.
  • Page 129 Appendix C: System Specifications Appendix C System Specifications Processors Single AMD EPYC™ 7002/7003 Series Processor Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset System on Chip BIOS 256 Mb SPI AMI BIOS SM Flash UEFI BIOS ®...
  • Page 130 A+ Server ASG -1014S-ACR12N4H User's Manual Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN EN55032 EN EN55035 EN 61000-3-2 EN 61000-3-3 EN 61000-4-2 EN 61000-4-3...
