  • Page 1 A+ Server AS -2114S-WN24RT USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found at our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................11 1.5 Motherboard Layout ......................12 Quick Reference Table ......................13 Chapter 2 Server Installation 2.1 Overview ..........................15 2.2 Preparing for Setup ......................15 Choosing a Setup Location ....................15...
  • Page 5 AS -2114S-WN24RT User's Manual Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................23 3.2 Accessing the System ......................23 3.3 Motherboard Components ....................24 Processor Installation ......................24 3.4 Memory Support and Installation ..................31 DIMM Module Population ....................32 DIMM Installation ......................33 DIMM Removal .........................33 PCI Expansion Card Installation ..................34 Motherboard Battery ......................35 3.5 Chassis Components ......................36...
  • Page 6 Preface Chapter 6 UEFI BIOS 6.1 Introduction .........................63 Starting the Setup Utility ....................63 6.2 Main Setup .........................64 6.3 Advanced ..........................66 6.4 IPMI ............................86 6.5 Event Logs .........................89 6.6 Security ..........................91 6.7 Boot ............................95 6.8 Save & Exit .........................97 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications Appendix C UEFI BIOS Recovery...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    Rack Rail Mounting Kit MCP-290-00053-0N Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the AS -2114S-WN24RT have been certified as compliant with UL or CSA: 216-R12H12 and A216B-H12.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the AS -2114S-WN24RT. Please refer to Appendix B for additional specifications. System Features Motherboard H12SSW-NTR Chassis CSE-216BTS-R1K23WBP Single EPYC 7002/7003 Series processor Socket Type SP3 socket Memory...

  • Page 10: Server Chassis Features

    AS -2114S-WN24RT User's Manual 1.4 Server Chassis Features Control Panel There are two buttons located on the front of the chassis: a power on/off button and a UID button. In addition there are five LEDs. The locations of these buttons and LEDs on the control panel are described below.

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The CSE-216BTS-R1K23WBP is a 2U chassis See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Drive Bays Drive bays for 2.5" hot-swap NVMe drives Control Panel Server control panel.

  • Page 12: Motherboard Layout

    AS -2114S-WN24RT User's Manual 1.5 Motherboard Layout Below is a layout of the H12SSW-NTR with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. USB 2/3 LAN 2 COM1...

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 Clear CMOS Open (Normal) JPL1 LAN Enable/Disable Pins 1-2 (Enabled) JWD1 Watch Dog control Pins 1-2 (Reset) UID SW Unit ID switch (push-button toggle switch ON/OFF) Description Status LED1 UID LED Blue: UID Activated LED9...
  • Page 14 AS -2114S-WN24RT User's Manual H12SSW-NTR IPMI LAN RJ45 AMD SP3 Rev. 1.01 Rear USB 3.0 10Gb LAN 10Gb LAN RJ45 RJ45 Rear SXB1 SXB2 USB 3.0 COM1 RX 0-7 RX 15-8 ASM1042 ASM1042 TX 0-7 TX 15-8 USB controller USB controller CPU P3 [10] TX 0-15 RX 0-15...

  • Page 15: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 16: Server Precautions

    AS -2114S-WN24RT User's Manual • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 17: Circuit Overloading

    Chapter 2: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 18: Installing The Rails

    AS -2114S-WN24RT User's Manual 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 19: Releasing The Inner Rail

    Chapter 2: Server Installation Releasing the Inner Rail Releasing Inner Rail from the Outer Rails 1. Identify the left and right outer rail assemblies as described on the previous page. 2. Pull the inner rail out of the outer rail until it is fully extended as illustrated below. 3.

  • Page 20: Installing The Outer Rails On The Rack

    AS -2114S-WN24RT User's Manual Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 21: Standard Chassis Installation

    Chapter 2: Server Installation Standard Chassis Installation Installing the Chassis into a Rack 1. Confirm that the inner rails are properly installed on the chassis. 2. Confirm that the outer rails are correctly installed on the rack. 3. Pull the middle rail out from the front of the outer rail and make sure that the ball- bearing shuttle is at the front locking position of the middle rail.
  • Page 22 AS -2114S-WN24RT User's Manual Ball-Bearing Shuttle Figure 2-5. Installing the Server into a Rack Note: Figure is for illustrative purposes only. Always install servers to the bottom of a rack first.

  • Page 23: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 24: Motherboard Components

    Check that the plastic socket dust cover is in place and none of the socket pins are bent— otherwise, contact your retailer. • Refer to the Supermicro website for updates on CPU support. • Graphics in this manual are for illustration. Your components may look slightly different.
  • Page 25 Chapter 3: Maintenance and Component Installation Installing the Processor Begin by removing power from the system as described in Section 3.1. 1. Use a Torx T20 driver to loosen the screws holding down Force Frame in the sequence of 3-2-1. The screws are numbered on the Force Frame next to each screw hole. Screw #3 Screw #1 Screw #2...
  • Page 26 AS -2114S-WN24RT User's Manual 2. The spring-loaded Force Frame will raise up after the last screw (#1) is removed. Gently allow it to lift up to its stopping position. Figure 3-3. Raising the Force Frame 3. Lift the Rail Frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the Rail Frame, lift it to a position so you can do the next step of removing the External Cap.
  • Page 27 Chapter 3: Maintenance and Component Installation 4. Remove the External Cap from the Rail Frame by pulling it upwards through the rail guides on the Rail Frame. Remove the PnP Cover Cap. External Cap PnP Cover Cap Figure 3-5. Removing the External Cap 5.
  • Page 28 AS -2114S-WN24RT User's Manual Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the Rail Frame plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the Rail Frame plate again, and double-check that the CPU is aligned properly.
  • Page 29 Chapter 3: Maintenance and Component Installation Screw 3 Screw 2 Screw 1 Figure 3-8. Securing the Force Frame 10. Secure the screws in the order 1-2-3, tightening each to 16.1 kgf-cm (14 lbf-in) of torque using a Torx T20 driver. The Force Frame secures both the Rail Frame and CPU Package.
  • Page 30 AS -2114S-WN24RT User's Manual Un-installing the Processor and Heatsink 1. Remove the heatsink. 2. Clean the thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing. 3.

  • Page 31: Memory Support And Installation

    Chapter 3: Maintenance and Component Installation 3.4 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. The H12SSW-NTR has 16 DIMM slots that support up to 2 TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS memory in 16 slots.

  • Page 32: Dimm Module Population

    AS -2114S-WN24RT User's Manual DIMM Module Population There is no specific order or sequence required when installing memory modules. However do keep the following in mind: • Always use DDR4 DIMM modules of the same type, size and speed. • Mixed DIMM speeds can be installed.

  • Page 33: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Push the release tabs outwards on both ends of the DIMM slot to unlock it. 2. Align the key of the DIMM module with the receptive point on the memory slot. 3.

  • Page 34: Pci Expansion Card Installation

    AS -2114S-WN24RT User's Manual PCI Expansion Card Installation The AS -2114S-WN24RT can accommodate one expansion card in the Gen4 x16 PCIe slot indicated below. The remaining slots are populated with Gen4 retimer cards by default. Installing an Expansion Card 1. Begin by removing power from the system. 2.

  • Page 35: Motherboard Battery

    Chapter 3: Maintenance and Component Installation Figure 3-13. Installing Riser Card to Bracket Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in Section 3.1 and removing the cover as described in Section 3.2.

  • Page 36: Chassis Components

    AS -2114S-WN24RT User's Manual 3.5 Chassis Components Hard Drives Up to 24 hot-swap 2.5" hard drives are supported by the chassis. The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. (Both procedures may be done without removing power from the system.) Removing a Hot-Swap Drive Carrier 1.

  • Page 37: Hard Drive Carrier Indicators

    Figure 3-16. Mounting a Drive in a Carrier Figure 3-17. Installing a Drive Carrier into its Bay Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.

  • Page 38: Installing The Rear 2.5" Hard Drive

    AS -2114S-WN24RT User's Manual Figure 3-18. Drive Bays: Logical Configuration Installing the Rear 2.5" Hard Drive The CSE-216BTS model chassis supports an optional hard drive cage for two additional 2.5" hot-swappable hard drives. The hard drive cage installs in the rear of the chassis next to the power supply.
  • Page 39 Chapter 3: Maintenance and Component Installation 3. Place the hard drive cage into the chassis. Secure the front of the hard drive cage to the chassis by fastening one screw inside the opening of the hard drive cage as illustrated. 4.

  • Page 40: System Cooling

    AS -2114S-WN24RT User's Manual System Cooling Three 8-cm hot-swap chassis fans provide the cooling for the AS -2114S-WN24RT. It is very important that the top cover of the chassis is properly installed in order for the cooling air to circulate properly through the chassis and cool the components. System Fan Failure Fan speed is controlled by system temperature via IPMI.

  • Page 41: Air Shrouds

    Chapter 3: Maintenance and Component Installation Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The AS -2114S-WN24RT air shrouds do not require screws for installation. Installing the Main Air Shroud Begin by removing power from the system as described in Section 3.1. 1.

  • Page 42: Installing An M.2 Solid State Drive

    AS -2114S-WN24RT User's Manual Installing an M.2 Solid State Drive Note: There are some thermal limitations with M.2 drives. Please contact Supermicro Support before installing an M.2 device. The motherboard can accommodate an M.2 solid state drive (SSD). The M.2 socket supports NVMe PCIe 3.0 x2 (32 Gb/s) SSD cards in the 2280 or 22110 form factors.

  • Page 43: Power Supply

    Chapter 3: Maintenance and Component Installation Power Supply The AS -2114S-WN24RT has two redundant, hot-plug 1200 Watt power supplies. The power modules are hot-swappable, enabling them to be replaced without powering down the system. These power supplies are auto-switching capable, allowing them to automatically sense and operate at a 100v to 240v input voltage.
  • Page 44 AS -2114S-WN24RT User's Manual Release Tab Figure 3-23. Replacing a Power Supply Module...

  • Page 45: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 46 AS -2114S-WN24RT User's Manual 12V 8-pin Auxiliary Power Connector (JPWR1) JPWR1 is an 8-pin ATX power input to provide auxiliary power to the processor. Refer to the table below for pin definitions. 12V 8-pin Power Connector Pin Definitions Pins Definition 1 through 4 Ground 5 through 8...

  • Page 47: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Onboard Fan Headers (FAN1~FAN6) There are six fan headers on the motherboard. These are 4-pin fan headers; pins 1-3 are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled by Thermal Management (via Hardware Monitoring) in the BMC.
  • Page 48 It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Please go to the following link for more information on TPM: http://www.supermicro.com/ manuals/other/TPM.pdf. Trusted Platform Module Header...
  • Page 49 Chapter 4: Motherboard Connections USB Ports (USB0~USB4, USB6/7) There are a total of seven USB ports supported on the motherboard. Four are located on the back panel , USB0/1, and USB2/3 via ASM1042 (both are USB 3.0 compliant). There are also three ports located on the motherboard, two are on one header, USB6/7 (3.0) and and the remaining one is on a 3.0 "Type A"...
  • Page 50 AS -2114S-WN24RT User's Manual Chassis Intrusion (JL1) A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to the header to inform you when the chassis is opened. Chassis Intrusion Pin Definitions Pins Definition Ground...

  • Page 51: Control Panel

    Chapter 4: Motherboard Connections Control Panel JF1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 52 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com. UID LED Pin Definitions (JF1)
  • Page 53 Chapter 4: Motherboard Connections HDD LED/UID Switch The HDD LED/UID Switch connection is located on pins 13 and 14 of JF1. Attach a cable to Pin 14 to show hard drive activity status. Attach a cable to Pin 13 to use UID switch. Refer to the table below for pin definitions.

  • Page 54: Rear I/O Ports

    AS -2114S-WN24RT User's Manual 4.3 Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description Description COM Port USB 2 (3.0) VGA Port IPMI LAN Port...
  • Page 55 See page 36 for the front panel UID LED header location on JF1. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com...

  • Page 56: Jumpers

    AS -2114S-WN24RT User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 57 Chapter 4: Motherboard Connections Watch Dog (JWD1) JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 58: Led Indicators

    AS -2114S-WN24RT User's Manual 4.5 LED Indicators LAN Port LEDs The motherboard's Ethernet ports has two LED indicators. The Activity LED is green and indicates connection and activity. The Link LED may be green, orange/amber, or off to indicate the speed of the connection. Refer to the tables below for more information. Link LED, Connection Link, Speed Indicator Activity LED...

  • Page 59: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 60 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 61: Driver Installation

    AS -2114S-WN24RT User's Manual 5.2 Driver Installation The Supermicro website contains drivers and utilities for your system at www.supermicro.com/ wdl/driver/AMD/SP3. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard.

  • Page 62: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 63: Chapter 6 Uefi Bios

    Chapter 6: UEFI BIOS Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the H12SSW-NTR motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 64: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2015 after RTC reset. Supermicro H12SSW-NTR BIOS Version This item displays the version of the BIOS ROM used in the system.
  • Page 65 Chapter 6: UEFI BIOS Build Date This item displays the date when the version of the BIOS ROM used in the system was built. CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This feature displays the total system memory detected.

  • Page 66: Advanced

    AS -2114S-WN24RT User's Manual 6.3 Advanced Use the arrow keys to select a top item and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 67 Chapter 6: UEFI BIOS Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are On and Off. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 68 AS -2114S-WN24RT User's Manual Trusted Computing  Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security.
  • Page 69 Chapter 6: UEFI BIOS Super IO Configuration The following Super IO information will display: • Super IO Chip AST2500 Serial Port 1 Configuration Serial Port Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled. Device Settings This item displays the status of a serial part specified by the user.
  • Page 70 AS -2114S-WN24RT User's Manual *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support.
  • Page 71 Chapter 6: UEFI BIOS Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 72 AS -2114S-WN24RT User's Manual Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 73 Chapter 6: UEFI BIOS Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 74 AS -2114S-WN24RT User's Manual Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII character set. Select VT100+ to add color and function key support. Select ANSI to use the extended ASCII character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 75 Chapter 6: UEFI BIOS Core Performance Boost This setting is used to configure for Core Performance Boost. Options include Disabled and Auto. Global C-state Control This setting is used to configure for Global C-state Control. Options include Disabled, Enabled, and Auto. Local APIC Mode This setting is used for Local APIC Mode.
  • Page 76 AS -2114S-WN24RT User's Manual • L2 Data Cache (Size/Method) • L3 Cache per Scoket (Size/Method) NB Configuration  North Bridge Configuration Determinism Control Use this setting to configure the Determinism Slider. The options include Manual and Auto. cTDP Control Use this setting to configure the cTDP Control. The options include Manual and Auto. IOMMU Use this setting to enable/disable IOMMU.
  • Page 77 Chapter 6: UEFI BIOS Memory Interleaving Size This setting controls the memory interleaving size. This determines the starting address of the interleave (bit 8, 9, 10 or 11). The options are 256 Bytes, 512 Bytes, 1 KB, 2 KB or Auto. Chipset Interleaving This setting controls interleave memory blocks across the DRAM chip for node 0.
  • Page 78 AS -2114S-WN24RT User's Manual PCIe ARI Support Use this setting to enable/disable Alternative Routing-ID Interpretation (ARI). The options are Disabled, Enabled and Auto. PCIe Spread Spectrum Use this setting to Disable or Enable PCIe Spread Spectrum for your system. Target Link Speed If supported by hardware and set to Force to x.S GT/S (x being a value of 2.5, 5.0 or 8.0) for Downstream Ports, this sets an upper limit on Link Operational Speed by restricting the values advertised by the UPstream component in its training sequences.
  • Page 79 Chapter 6: UEFI BIOS Onboard LAN1 Option ROM Use this setting to select which option ROM is to be loaded for onboard LAN1 on the system. Options include Disabled, Legacy and EFI. Onboard LAN2 Option ROM Use this setting to select which firmware function is to be loaded for onboard LAN2 on the system.
  • Page 80 AS -2114S-WN24RT User's Manual USB Configuration Legacy USB Support Select Enabled to support onboard legacy USB devices. Select Auto to disable legacy support if there are no legacy USB devices present. Select Disable to have all USB devices available for EFI applications only. The options are Enabled, Disabled and Auto. XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Extensible Host Controller Interface) hand-off.
  • Page 81 Chapter 6: UEFI BIOS ASMedia SATA Information This section displays information on the detected ASMedia SATA devices: • SATA Mode SATA Configuration SATA Enable This item enables or disables the onboard SATA controller supported by the Intel PCH chip. The options are Enabled and Disabled. SATA Hotplug This item enables or disables the onboard SATA controller's hot plug feature (PCH).
  • Page 82 AS -2114S-WN24RT User's Manual Enter Configuration Menu  Create New VLAN VLAN ID This option is an input field used to enter a unique numeric VLAN ID. The valid range is from 0~4096. Priority This option is an input field used to enter a unique numeric VLAN 802.1Q priority. The valid range is from 0~7.
  • Page 83 Chapter 6: UEFI BIOS Local Gateway This item sets the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1). Local DNS This item sets the address for the local DNS servers for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1).
  • Page 84 AS -2114S-WN24RT User's Manual  Change Attempt Order TLS Authentication Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification Using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.
  • Page 85 Chapter 6: UEFI BIOS Create raw This feature allows the user to create a raw RAM disk from all available memory modules in the system. When you select this submenu and press <Enter>, the following items will display: • Size (Hex): Use this feature to set the size of the raw RAM disk. The default setting is 1. •...

  • Page 86: Ipmi

    AS -2114S-WN24RT User's Manual 6.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system.
  • Page 87 Chapter 6: UEFI BIOS Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 88 AS -2114S-WN24RT User's Manual Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form. Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255.

  • Page 89: Event Logs

    Chapter 6: UEFI BIOS 6.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 90 AS -2114S-WN24RT User's Manual When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.

  • Page 91: Security

    Chapter 6: UEFI BIOS 6.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well. Password Check Select Setup for the system to check for a password at Setup.
  • Page 92 AS -2114S-WN24RT User's Manual This option allows you specify when the Platform Key (PK) is enrolled. When enabled, the System Mode is user deployed, and the CSM function is disabled. Options include Disabled and Enabled . Secure Boot Mode Use this item to select the secure boot mode. The options are Standard and Custom. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot.
  • Page 93 Chapter 6: UEFI BIOS Restore DB defaults Select and press Yes to restore the DB variables to factory defaults. The options are Yes and No. Platform Key (PK) This feature allows the user to configure the settings of the platform keys. Set New Key Select Yes to load the new platform keys (PK) from the manufacturer's defaults.
  • Page 94 AS -2114S-WN24RT User's Manual Authorized TimeStamps Set New Key Select Yes to load the DBT from the manufacturer's defaults. Select No to load the DBT from a file. The options are Yes and No. Append Key Select Yes to add the DBT from the manufacturer's defaults list to the existing DBT. Select No to load the DBT from a file.

  • Page 95: Boot

    Chapter 6: UEFI BIOS 6.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are LEGACY, UEFI, and DUAL. The default setting is DUAL. Legacy to EFI Support This option Enables or Disables the system to boot to an EFI OS after the boot failed from the legacy boot order.
  • Page 96 AS -2114S-WN24RT User's Manual  UEFI Application Boot Priorities This feature allows the user to specify which UEFI devices are boot devices. • UEFI Boot Order #1  NETWORK Drive BBS Priorities This feature allows the user to specify which UEFI network drive devices are boot devices.

  • Page 97: Save & Exit

    Chapter 6: UEFI BIOS 6.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 98 AS -2114S-WN24RT User's Manual Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance.

  • Page 99: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 100 Appendix A: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 101 AS -2114S-WN24RT User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 102 Appendix A: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 103 AS -2114S-WN24RT User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 104 Appendix A: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 105 AS -2114S-WN24RT User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 106 Appendix A: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 107 AS -2114S-WN24RT User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 108 Appendix A: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 109 AS -2114S-WN24RT User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 110 Appendix A: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 111 AS -2114S-WN24RT User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 112 Appendix A: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 113 AS -2114S-WN24RT User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 114 Appendix A: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 115 AS -2114S-WN24RT User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 116 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 117 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 118 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 119: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single EPYC 7002/7003 Series processor in an SP3 socket Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset System on Chip chipset BIOS 128 Mb SPI AMI BIOS Flash EEPROM ®...
  • Page 120 AS -2114S-WN24RT User's Manual Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN 55032 EN 55035 CISPR 32 CISPR 24/CISPR 35 EN 61000-3-2...

  • Page 121: Appendix C Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 122 USB flash drive with FAT16 or FAT32 format and rename the file to SUPER.ROM. Note: If you cannot locate the "SUPER.ROM" file in your driver disk, visit our website at www.supermicro.com to download the correct BIOS image into a USB flash device and rename it "SUPER.ROM".
  • Page 123 SUPERMICO BIOS Update: https://www.youtube.com/watch?v=S8z6iOEHGwY * If the BIOS flash recovery fails, contact our RMA Department to have the BIOS chip reprogrammed. This will require shipping the board to Supermicro for repair. Submit your RMA request at https://www.supermicro.com/support/rma Please make sure to follow all instructions when returning the motherboard.
