AP580E / AP580E-POE AcroPack
1Gb Ethernet (Power over Ethernet) Module
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: solutions@acromag.com
Copyright 2016, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501099E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Acromag AcroPack AP580E
Summary of Contents for Acromag AcroPack AP580E
- Page 1 1Gb Ethernet (Power over Ethernet) Module USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 295-0310 Email: solutions@acromag.com Copyright 2016, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8501099E...
-
Page 2: Table Of Contents
Table 2.2 Logic Interface connector Pin Assignments ..............12 2.9 LEDs ........................... 13 3.0 SERVICE AND REPAIR ....................13 3.1 Service and Repair Assistance ..................13 3.2 Preliminary Service Procedure ..................14 Acromag, Inc. Tel: 248-295-0310 - 1 - - 1 - https://www.acromag.com http://www.acromag.com... - Page 3 4.3.4 EMC Directives ..........................17 4.4 Reliability Prediction ....................18 AP580E-LF ............................18 AP580E-POE-LF ............................18 4.5 PCIe Bus Specifications ....................18 APPENDIX ..........................19 CERTIFICATE OF VOLATILITY ..................19 REVISION HISTORY ......................20 Acromag, Inc. Tel: 248-295-0310 - 2 - - 2 - https://www.acromag.com...
-
Page 4: General Information
The information contained in this manual is subject to change without notice, and Acromag, Inc. (Acromag) does not guarantee its accuracy. Acromag makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. -
Page 5: Acropack Information - All Models
Intel I210 1Gb Ethernet Controller • Single Port • Audio Video bridging o IEEE 1588/802.1AS precision time synchronization o IEEE 802.1Qav traffic shaper (with software extensions) • Jumbo frames Acromag, Inc. Tel: 248-295-0310 - 4 - - 4 - https://www.acromag.com... -
Page 6: Key Features Pcie Interface
Compatibility – PCI Express Base Specification v2.1 compliant PCI Express Endpoint. 1.4 Signal Interface Products This AcroPack Module will mate directly to all Acromag AP carriers. Once connected, the module is accessed via a 50 pin or 68 pin panel connector. The cables and termination panels are also available. -
Page 7: Preparation For Use
It is important that the user employ satisfactory overall system design. It is understood and agreed by the Buyer and Acromag that this is the Buyer's responsibility. -
Page 8: Installation Considerations
Refer to the specifications section for loading and power requirements. Be sure that the system power supplies are able to accommodate the power IMPORTANT: Adequate air requirements of the system boards, plus the installed Acromag board, circulation must be provided to within the voltage tolerances specified. -
Page 9: Field I/O Connector
MDI1- /RJ45 Pin 6 (POE DC-) Reserved/isolation Reserved/isolation MDI2+ /RJ45 Pin 4 MDI2- /RJ45 Pin 5 Reserved/isolation Reserved/isolation MDI3+ /RJ45 Pin 7 MDI3- /RJ45 Pin 8 Reserved/isolation Reserved/isolation Reserved/isolation Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 8 - - 8 - https://www.acromag.com... - Page 10 Reserved/isolation POE INPUT 12VDC+ POE INPUT 12VDC+ Reserved/isolation Reserved/isolation POE INPUT 12VDC+ POE INPUT 12VDC+ Reserved/isolation Reserved/isolation POE INPUT 12VDC+ POE INPUT 12VDC+ Reserved/isolation Reserved/isolation POE INPUT 12VDC+ Acromag, Inc. Tel: 248-295-0310 - 9 - - 9 - https://www.acromag.com http://www.acromag.com...
- Page 11 POE INPUT 12VDC+ POE INPUT 12VDC+ Reserved/isolation Reserved/isolation LAN LINK 100 LED Reserved/isolation Reserved/isolation LAN LINK 1000 LED Reserved/isolation Reserved/isolation LAN Activity LED Reserved/isolation Reserved/isolation Reserved/isolation Reserved/isolation OUTPUT 3.3VDC Reserved/isolation Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 10 - - 10 - https://www.acromag.com...
- Page 12 See image of carrier. Note 2: APCe7020E-LF is an example of a carrier that uses the Champ connector. See image of carrier. Acromag, Inc. Tel: 248-295-0310 - 11 - - 11 - https://www.acromag.com http://www.acromag.com...
-
Page 13: Logic Interface Connector
Note 2: +5V, +12V, and -12V power supplies have been assigned to pins that are reserved in the mini-PCIe specification. Note 3: All +3.3Vaux power pins are changed to +3.3V power. Note 4: The signal is tied to circuit GND on the AP module. Acromag, Inc. Tel: 248-295-0310 - 12 - - 12 - https://www.acromag.com... -
Page 14: Leds
SMT repair and service tools are used. For these and other reasons, it is strongly recommended that a non-functioning board be returned to Acromag for repair. Acromag has automated diagnostic and test equipment that thoroughly checks the performance of suspect boards. -
Page 15: Preliminary Service Procedure
3.3 Where to Get Help For assistance from Acromag’s website go to the “Support” tab and submit/search the Acromag forum or fill out the contact us form. You can get additional documentation from your products webpage by using the search feature. If you’d like to speak with an application engineer please call 248-295-0310 or email solutions@acromag.com. -
Page 16: Specifications
• AcroPack L x W: 70 mm x 30.00 mm (2.76 in x 1.18 in) Unit Weight (does not include shipping material): • AcroPack 0.016 lbs. (0.0074 kg) Acromag, Inc. Tel: 248-295-0310 - 15 - - 15 - https://www.acromag.com http://www.acromag.com... -
Page 17: Power Requirements
1Gb Ethernet with POE -40°C to 70°C Note 1: The AP580 does not support the AcroPack Accessory AP-CC-01 (Conduction cool kit). : 200LFM (minimum) Air flow is required above 50°C Note 2 Acromag, Inc. Tel: 248-295-0310 - 16 - - 16 - https://www.acromag.com... -
Page 18: Other Environmental Requirements
Conducted RF Immunity (CRFI), per IEC 61000-4-6. • Emissions per EN 61000-6-4: Enclosure Port, per CISPR 16. Low Voltage AC Mains Port, per CISPR 16. Note: This is a Class A product Acromag, Inc. Tel: 248-295-0310 - 17 - - 17 - https://www.acromag.com http://www.acromag.com... -
Page 19: Reliability Prediction
Compatibility Conforms to PCI Express Base Specification, Revision 2.1 Line Speed Gen1 (2.5Gbps) Available through system connector Lane Operation 1-Lane 4K Memory Space Required One Base Address Register (BAR) Acromag, Inc. Tel: 248-295-0310 - 18 - - 18 - https://www.acromag.com... -
Page 20: Appendix
User Modifiable Function: Process to Sanitize: □ Yes □ No Acromag Representative Name: Title: Email: Office Phone: Office Fax: Russ Nieves Director of solutions@acromag.com 248-295-0310 248-624-9234 Sales and Marketing Acromag, Inc. Tel: 248-295-0310 - 19 - - 19 - https://www.acromag.com http://www.acromag.com... -
Page 21: Revision History
Memory size from 4 Meg x 1bit to 8 Meg x 1bit. 16 APR 2016 PDG/ARP Updated Section 3.3 Where to Get Help. 07 DEC 2020 ENZ/AMM Updated MTBF Numbers. Acromag, Inc. Tel: 248-295-0310 - 20 - - 20 - https://www.acromag.com...
