Acromag AcroPack AP48 Series User Manual

Counter timer module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Series AP48x AcroPack
Counter Timer Module
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: Solutions@acromag.com
Copyright 2016, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501060G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AcroPack AP48 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acromag AcroPack AP48 Series

Summary of Contents for Acromag AcroPack AP48 Series

  • Page 1 Series AP48x AcroPack Counter Timer Module USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 295-0310 Email: Solutions@acromag.com Copyright 2016, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8501060G...

  • Page 2: Table Of Contents

    Table 2.3 AP484 Field I/O Connector Pin Assignments .................17 NOTE 1: VPX4500-CC-LF IS AN EXAMPLE OF A CARRIER THAT USES THE RIBBON CABLE CONNECTOR SEE IMAGE OF CARRIER........... 19 Acromag, Inc. Tel: 248-295-0310 - 1 - - 1 - https://www.acromag.com...
  • Page 3 Frequency Measurement Operation ....................43 Table 3.15 Counter Control Register (Frequency Measurement) ..........44 Input Pulse Width Measurement ......................45 Table 3.16 Counter Control Register (Pulse Width Measurement) ........... 46 Input Period Measurement ........................47 Acromag, Inc. Tel: 248-295-0310 - 2 - - 2 - https://www.acromag.com...
  • Page 4 5.1 Service and Repair Assistance ..................57 5.2 Preliminary Service Procedure ..................57 5.3 Where to Get Help ...................... 57 6.0 SPECIFICATIONS ......................58 6.1 Physical ........................58 6.2 Power Requirements ....................58 Acromag, Inc. Tel: 248-295-0310 - 3 - - 3 - https://www.acromag.com http://www.acromag.com...
  • Page 5 Figure 2 AP483 Block Diagram ......................63 Figure 3 AP484 Block Diagram ......................64 APPENDIX A .......................... 65 AP-CC-01 Heatsink Kit Installation ..................65 CERTIFICATE OF VOLATILITY ..................68 REVISION HISTORY ......................69 Acromag, Inc. Tel: 248-295-0310 - 4 - - 4 - https://www.acromag.com...

  • Page 6: General Information

    The information contained in this manual is subject to change without notice, and Acromag, Inc. (Acromag) does not guarantee its accuracy. Acromag makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 7: Ordering Information

    TTL I/O – 482 Counter/Timer I/O is available as TTL only. Mixed TTL and RS422/RS485 I/O options are available on the 483 models. Only RS422/RS485 I/O is available on the 484 models. Acromag, Inc. Tel: 248-295-0310 - 6 - - 6 -...
  • Page 8 Internal or External Triggering – A software or hardware trigger is selectable to initiate quadrature position measurement, pulse width modulation, watchdog countdown, event counting, frequency measurement, pulse-width measurement, period measurement, or one shot. Acromag, Inc. Tel: 248-295-0310 - 7 - - 7 - https://www.acromag.com http://www.acromag.com...

  • Page 9: Key Features Pcie Interface

    Compatibility – PCI Express Base Specification v2.1 compliant PCI Express Endpoint. 1.4 Signal Interface Products This AcroPack Module will mate directly to all Acromag AP carriers. Once connected, the module is accessed via a front panel connector. The cables and termination panels are also available. For optimum performance with the AP440 digital I/O module, use of the shortest possible length of shielded I/O cable is recommended.

  • Page 10: Windows

    AcroPack modules, VPX I/O board products, and PCIe I/O Cards. The software is implemented as a library of “C” functions which link with existing user code to make possible simple control of all Acromag AcroPack modules. 1.6 References The following resources regarding AcroPack modules are available for download on Acromag’s website or by contacting your sales representative.

  • Page 11: Preparation For Use

    It is important that the user employ satisfactory overall system design. It is understood and agreed by the Buyer and Acromag that this is the Buyer's responsibility.

  • Page 12: Installation Considerations

    Refer to the specifications section for loading and power requirements. Be sure that the system power supplies are able to accommodate the power IMPORTANT: Adequate air requirements of the system boards, plus the installed Acromag board, circulation must be provided to within the voltage tolerances specified.
  • Page 13 Reserved/isolation Reserved/isolation In6_A In7_A Reserved/isolation Reserved/isolation In8_A In9_A Reserved/isolation Reserved/isolation In0_B In1_B Reserved/isolation Reserved/isolation In2_B In3_B Reserved/isolation Reserved/isolation In4_B In5_B Reserved/isolation Reserved/isolation In6_B In7_B Reserved/isolation Reserved/isolation In8_B In9_B Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 12 - - 12 - https://www.acromag.com...
  • Page 14 Reserved/isolation In8_C In9_C Reserved/isolation Reserved/isolation Din0 Din1 Reserved/isolation Reserved/isolation Out0 Out1 Reserved/isolation Reserved/isolation Out2 Out3 Reserved/isolation Reserved/isolation Out4 Out5 Reserved/isolation Reserved/isolation Out6 Out7 Reserved/isolation Reserved/isolation Out8 Out9 Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 13 - - 13 - https://www.acromag.com http://www.acromag.com...
  • Page 15 Field I/O Signal Carrier Connector Carrier Connector Connector Number In0_A In1_A Reserved/isolation Reserved/isolation In2_A In3_A Reserved/isolation Reserved/isolation In4_A In0_B Reserved/isolation Reserved/isolation In1_B In2_B Reserved/isolation Reserved/isolation In3_B In4_B Reserved/isolation Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 14 - - 14 - https://www.acromag.com...
  • Page 16 Out2 Out3 Reserved/isolation Reserved/isolation Out4 DOut0 Reserved/isolation Reserved/isolation DOut1 DOut2 Reserved/isolation Reserved/isolation In5_A+ In5_A- Reserved/isolation Reserved/isolation In5_B+ In5_B- Reserved/isolation Reserved/isolation In5_C+ In5_C- Reserved/isolation Reserved/isolation Out5+ Out5- Reserved/isolation Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 15 - - 15 - https://www.acromag.com http://www.acromag.com...
  • Page 17 In6_C+ In6_C- Reserved/isolation Reserved/isolation Out6+ Out6- Reserved/isolation Reserved/isolation In7_A+ In7_A- Reserved/isolation Reserved/isolation In7_B+ In7_B- Reserved/isolation Reserved/isolation In7_C+ In7_C- Reserved/isolation Reserved/isolation Out7+ Out7- Reserved/isolation Reserved/isolation External Clock Enable Reserved/isolation Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 16 - - 16 - https://www.acromag.com...
  • Page 18 Reserved/isolation Out0+ Out0- Reserved/isolation Reserved/isolation In1_A+ In1_A- Reserved/isolation Reserved/isolation In1_B+ In1_B- Reserved/isolation Reserved/isolation In1_C+ In1_C- Reserved/isolation Reserved/isolation Out1+ Out1- Reserved/isolation Reserved/isolation In2_A+ In2_A- Reserved/isolation Reserved/isolation In2_B+ In2_B- Reserved/isolation Acromag, Inc. Tel: 248-295-0310 - 17 - - 17 - https://www.acromag.com http://www.acromag.com...
  • Page 19 In3_B- Reserved/isolation Reserved/isolation In3_C+ In3_C- Reserved/isolation Reserved/isolation Out3+ Out3- Reserved/isolation Reserved/isolation In4_A+ In4_A- Reserved/isolation Reserved/isolation In4_B+ In4_B- Reserved/isolation Reserved/isolation In4_C+ In4_C- Reserved/isolation Reserved/isolation Out4+ Out4- Reserved/isolation Reserved/isolation In5_A+ In5_A- Acromag, Inc. Tel: 248-295-0310 - 18 - - 18 - https://www.acromag.com...

  • Page 20: Note 1: Vpx4500-Cc-Lf Is An Example Of A Carrier That Uses The Ribbon Cable Connector See Image Of Carrier

    Out5+ Out5- Reserved/isolation Reserved/isolation External Clock Enable Reserved/isolation Reserved/isolation Note 1: VPX4500-CC-LF is an example of a carrier that uses the ribbon cable connector see image of carrier. Acromag, Inc. Tel: 248-295-0310 - 19 - - 19 - https://www.acromag.com http://www.acromag.com...

  • Page 21: Note 2: Apce7020E-Lf Is An Example Of A Carrier That Uses The Champ Connector See Image Of Carrier

    JTAG signals TMS and TCK. Lastly, UIM_C4, UIM_C8 – reserved User Identity Module signals are reassigned to JTAG signals TDI and TDO. Table 2.4: Logic Interface Connections Acromag, Inc. Tel: 248-295-0310 - 20 - - 20 - https://www.acromag.com...
  • Page 22 Note 4: The SM bus signals SMB_CLK and SMB_DATA will be used to clock a carrier location serial stream from the carrier. These signals are under the control of the AcroPack module. Acromag, Inc. Tel: 248-295-0310 - 21 - - 21 - https://www.acromag.com...

  • Page 23: Programming Information

    Address Registers and the Interrupt Register which must be read to determine the base address assigned to the board and the interrupt request that goes active on a board interrupt request. Acromag, Inc. Tel: 248-295-0310 - 22 - - 22 -...
  • Page 24 Counters Interrupt Status/Clear 0x0000 0008 15:0 “Not Used”. The board Register will return “0” for all Counter Interrupt Enable/Disable 0x0000 000C address reads that are Register not used or reserved. Acromag, Inc. Tel: 248-295-0310 - 23 - - 23 - https://www.acromag.com http://www.acromag.com...
  • Page 25 Counter 2 Constant A Register 0x0000 0070 31:0 Counter 2 Constant A Register2 0x0000 0074 31:0 Counter 2 Constant B Register 0x0000 0078 31:0 Counter 2 Constant B Register2 Acromag, Inc. Tel: 248-295-0310 - 24 - - 24 - https://www.acromag.com...
  • Page 26 0x0000 00D8 31:0 Counter 5 Constant B Register2 0x0000 00DC 31:0 NOT USED 0x0000 00E0 15:0 Counter 6 Control Register Counter 6 Interrupt Information 0x0000 00E4 15:0 Register Acromag, Inc. Tel: 248-295-0310 - 25 - - 25 - https://www.acromag.com http://www.acromag.com...
  • Page 27 Counter 9 Interrupt Information 0x0000 0144 15:0 Register 0x0000 0148 31:0 Counter 9 Read Back Register 0x0000 014C 31:0 Counter 9 Constant A Register 0x0000 0150 31:0 Counter 9 Constant A Register2 Acromag, Inc. Tel: 248-295-0310 - 26 - - 26 - https://www.acromag.com...

  • Page 28: Global Interrupt Enable Status Register (Read/Write) - (Bar0 + 0X0000 0000)

    When this bit is logic “0” an interrupt is not being requested. No Interrupt Interrupt Pending 14 to 2 Not Used Software Reset Acromag, Inc. Tel: 248-295-0310 - 27 - - 27 - https://www.acromag.com http://www.acromag.com...

  • Page 29: Module Location In System Register (Read Only) - (Bar0 + 0X0000 0004)

    A Counter/Timer interrupt can be cleared by writing a “1” to its bit position in the Interrupt Status/Clear Register (writing a “1” acts as a reset signal to clear the set state). The interrupt will be generated again, if the Acromag, Inc. Tel: 248-295-0310 - 28 - - 28 -...

  • Page 30: Counter Interrupt Enable/Disable Register (Read/Write) - (Bar0 + 0X0000 000C)

    Table 3.6 Counter Interrupt Enable Register FUNCTION Counter/Timer 0 Enable/Disable Interrupts Note that any registers/bits not mentioned will remain at Counter/Timer 1 Enable/Disable Interrupts the default value logic low. Acromag, Inc. Tel: 248-295-0310 - 29 - - 29 - https://www.acromag.com http://www.acromag.com...

  • Page 31: Counter Trigger Register (Write) - (Bar0 + 0X0000 0010)

    Counter 2 Trigger Counter 3 Trigger Counter 4 Trigger Counter 5 Trigger Counter 6 Trigger Counter 7 Trigger Counter 8 Trigger Counter 9 Trigger Acromag, Inc. Tel: 248-295-0310 - 30 - - 30 - https://www.acromag.com...

  • Page 32: Counter Stop Register (Write) - (Bar0 + 0X0000 0014)

    5 and 4 are set “11” will load the read back register. With Quadrature mode a pulse on InC when the Control register bits 9, 8 and 7 are set to “111” will load the read back register. Acromag, Inc. Tel: 248-295-0310 - 31 - - 31 - https://www.acromag.com...

  • Page 33: Toggle Counter Constants Register (Read/Write) - (Bar0 + 0X0000 001C)

    Counter 1 Toggle Counter Constants Register the default value logic low. Counter 2 Toggle Counter Constants Register Counter 3 Toggle Counter Constants Register Counter 4 Toggle Counter Constants Register Acromag, Inc. Tel: 248-295-0310 - 32 - - 32 - https://www.acromag.com...

  • Page 34: Counter Control Register (Read/Write)

    The following sections describe the features of each method of operation and how to best use them. Acromag, Inc. Tel: 248-295-0310 - 33 - - 33 - https://www.acromag.com...

  • Page 35: Quadrature Position Measurement

    X1, X2, and X4 which are programmed via counter timer control register bits 5 and 4. Channel B is enabled for input by setting bit-6 to a logic “1”. Acromag, Inc. Tel: 248-295-0310 - 34 - - 34 -...
  • Page 36 InC / Hardware Load Read Back Register InC = 0: Inactive State InC = 1: Load Read Back Register on logic high pulse 12,11,10 Counter Operational Frequency Select 1.953125MHz 3.90625MHz 7.8125MHz 15.625MHz Acromag, Inc. Tel: 248-295-0310 - 35 - - 35 - https://www.acromag.com http://www.acromag.com...
  • Page 37 Encoder output signals can be noisy. It is recommended that the InA, InB, and InC input signals be debounced by setting bit-15 of the Counter Control register to logic “1”. Noise transitions less than 2.4s will be removed with debounce enabled. Acromag, Inc. Tel: 248-295-0310 - 36 - - 36 - https://www.acromag.com...

  • Page 38: Pulse Width Modulation

    Thus, an interrupt is generated at each pulse transition. Acromag, Inc. Tel: 248-295-0310 - 37 - - 37 - https://www.acromag.com...
  • Page 39 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Enabled – Reject Gate-Off or Trigger Pulses (noise) less than or equal to 2.4s. Acromag, Inc. Tel: 248-295-0310 - 38 - - 38 - https://www.acromag.com...

  • Page 40: Watchdog Timer Operation

    0, if enabled via the Interrupt Enable/Disable Register. This could be useful for alerting the host that a watchdog timer time-out has occurred and may need to be reinitialized. The interrupt will remain Acromag, Inc. Tel: 248-295-0310 - 39 - - 39 - https://www.acromag.com...
  • Page 41 External InB CNTInB External Clock (pin Up to 15MHz 14 ,13 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Acromag, Inc. Tel: 248-295-0310 - 40 - - 40 - https://www.acromag.com...

  • Page 42: Event Counting Operation

    The Counter Constant A Register holds the count-to value (constant). Reading the Counter Read Back Register will return the current count (variable). The Counter Constant A value must not be left as 0. The counter upon trigger Acromag, Inc. Tel: 248-295-0310 - 41 - - 41 - https://www.acromag.com...
  • Page 43 Count Control 12,11,10 Specifies the Counter Mode: Event Counting 14 ,13 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Acromag, Inc. Tel: 248-295-0310 - 42 - - 42 - https://www.acromag.com...

  • Page 44: Frequency Measurement Operation

    Programmable clock selection is not available for frequency measurement. If interrupts are enabled via the Enable/Disable Interrupts Register, an interrupt is generated when the input InA enable pulse goes inactive. An Acromag, Inc. Tel: 248-295-0310 - 43 - - 43 - https://www.acromag.com...
  • Page 45 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Enabled – Reject Gate-Off or Trigger Pulses (noise) less than or equal to 2.4s. Acromag, Inc. Tel: 248-295-0310 - 44 - - 44 - https://www.acromag.com...

  • Page 46: Input Pulse Width Measurement

    (the pulse has returned to the opposite polarity), if enabled via the interrupt Enable/Disable Register. The interrupt will remain pending until released by setting the required bit of the Interrupt Status/Clear register. Acromag, Inc. Tel: 248-295-0310 - 45 - - 45 - https://www.acromag.com...
  • Page 47 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Enabled – Reject Gate-Off or Trigger Pulses (noise) less than or equal to 2.4s. Acromag, Inc. Tel: 248-295-0310 - 46 - - 46 - https://www.acromag.com...

  • Page 48: Input Period Measurement

    InB. The count value will be zero in this case. The interrupt, once driven active, will remain pending until released by setting the required bit of the Interrupt Status/Clear register. Acromag, Inc. Tel: 248-295-0310 - 47 - - 47 - https://www.acromag.com...
  • Page 49 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Enabled – Reject Gate-Off or Trigger Pulses (noise) less than or equal to 2.4s. Acromag, Inc. Tel: 248-295-0310 - 48 - - 48 - https://www.acromag.com...

  • Page 50: One-Shot Pulse Mode

    The interrupt will remain pending until released by setting the required bit of the Interrupt Status/Clear register. Acromag, Inc. Tel: 248-295-0310 - 49 - - 49 - https://www.acromag.com...
  • Page 51 Not Used (bits read back as 0) Input Debounce Enable Disabled (Default) – No Debounce Applied to any Input. Enabled – Reject Gate-Off or Trigger Pulses (noise) less than or equal to 2.4s. Acromag, Inc. Tel: 248-295-0310 - 50 - - 50 - https://www.acromag.com...

  • Page 52: Counter Interrupt Information Register (Read Only)

    The internal counter is generally initialized with the value in the Counter Constant Register, and its value is incremented or decremented according to the application. This register must be read using 32-bit accesses. Acromag, Inc. Tel: 248-295-0310 - 51 - - 51 - https://www.acromag.com...

  • Page 53: Counter Constant A Register (Read/Write)

    32-bit basis, only. The contents of the Counter Constant B and Counter Constant B Register 2 can be toggled for the counter/timers. Writing a “1” to the counter’s Acromag, Inc. Tel: 248-295-0310 - 52 - - 52 -...

  • Page 54: Digital Input Register (Read Only) - (Bar0 + 0X0000 0160)

    Dout 0 Note that any registers/bits not mentioned will remain at Dout 1 the default value logic low. Dout 2 Dout 3 Dout 4 Dout 5 6-31 Not Used Acromag, Inc. Tel: 248-295-0310 - 53 - - 53 - https://www.acromag.com http://www.acromag.com...

  • Page 55: Xadc Status/Control Register (Read/Write) - (Bar0 + 168H)

    Table 3.22: System Monitor 0x00 Temperature Register Map 0x01 Vccint 0x02 Vccaux 0x20 Maximum Temperature 0x21 Maximum Vccint 0x22 Maximum Vccaux 0x24 Minimum Temperature 0x25 Minimum Vccint 0x26 Minimum Vccaux Acromag, Inc. Tel: 248-295-0310 - 54 - - 54 - https://www.acromag.com...

  • Page 56: Firmware Revision Register (Read Only) - (Bar0 + 0X0000 0200)

    MCS firmware file is readable from this location. For example if the firmware is at revision A then this register will read 0x41 in the least significant byte or B= 0x42, C=0x43, etc. Acromag, Inc. Tel: 248-295-0310 - 55 - - 55 - https://www.acromag.com...

  • Page 57: Theory Of Operation

    PCIe specification. The program for the FGPA is stored in separate Flash memory and loaded upon power-up. Acromag, Inc. Tel: 248-295-0310 - 56 - - 56 - https://www.acromag.com...

  • Page 58: Service And Repair

    SMT repair and service tools are used. For these and other reasons, it is strongly recommended that a non-functioning board be returned to Acromag for repair. Acromag has automated diagnostic and test equipment that thoroughly checks the performance of suspect boards.

  • Page 59: Specifications

    AcroPack module. 6.3.1 Operating Temperature Model Number Temp Range I/O Type 32-bit Counters AP482E-LF C to 85 AP483E-LF C to 85 RS422/RS485 AP484E-LF C to 85 RS422/RS485 Acromag, Inc. Tel: 248-295-0310 - 58 - - 58 - https://www.acromag.com...

  • Page 60: Other Environmental Requirements

    Conducted RF Immunity (CRFI), per IEC 61000-4-6. • Emissions per EN 61000-6-4: Enclosure Port, per CISPR 16. Low Voltage AC Mains Port, per CISPR 16. Note: This is a Class A product Acromag, Inc. Tel: 248-295-0310 - 59 - - 59 - https://www.acromag.com http://www.acromag.com...

  • Page 61: Reliability Prediction

    Input signal with duration less then 2.4s are filtered with debounce enabled via counter control register. Counter Clock Enable 62.5MHz, 15.625MHz, 7.8125MHz, 3.90625MHz, 1.953125MHz or External Frequencies up to 15MHz Acromag, Inc. Tel: 248-295-0310 - 60 - - 60 - https://www.acromag.com...

  • Page 62: Pcie Bus Specifications

    Compatibility Conforms to PCI Express Base Specification, Revision 2.1 Line Speed Gen1 (2.5Gbps) Available through front connector Lane Operation 1-Lane 4K Memory Space Required One Base Address Register Acromag, Inc. Tel: 248-295-0310 - 61 - - 61 - https://www.acromag.com http://www.acromag.com...
  • Page 63 Simple write operations are just as fast as DMA read operations. Write data is presented to the AcroPack in one transaction. Measured 4-byte back to back write accesses taking place every 100ns. Acromag, Inc. Tel: 248-295-0310 - 62 - - 62 -...
  • Page 64 USER’S MANUAL SERIES AP48X ACROPACK Figure 1 AP482 Block Diagram Figure 2 AP483 Block Diagram Acromag, Inc. Tel: 248-295-0310 - 63 - - 63 - https://www.acromag.com http://www.acromag.com...
  • Page 65 USER’S MANUAL SERIES AP48X ACROPACK Figure 3 AP484 Block Diagram Acromag, Inc. Tel: 248-295-0310 - 64 - - 64 - https://www.acromag.com...

  • Page 66: Ap-Cc-01 Heatsink Kit Installation

    AP-CC-01 Heatsink Kit Installation Hardware Bottom view Top view AP-CC-01 Heat Sink Kit This example will show how to install the AP-CC-01 Heatsink kit with an APCe7020 carrier. Acromag, Inc. Tel: 248-295-0310 - 65 - - 65 - https://www.acromag.com http://www.acromag.com...
  • Page 67 USER’S MANUAL SERIES AP48X ACROPACK 1. Install two standoffs and secure with two screws. 2. Install the AcroPack module. 3. Install the Heatsink and secure with 4 screws. Acromag, Inc. Tel: 248-295-0310 - 66 - - 66 - https://www.acromag.com...
  • Page 68 USER’S MANUAL SERIES AP48X ACROPACK 4. AP-CC-01 Installation is complete. Note: Make sure the thermal pad is making contact with the FPGA IC. Acromag, Inc. Tel: 248-295-0310 - 67 - - 67 - https://www.acromag.com http://www.acromag.com...

  • Page 69: Certificate Of Volatility

    1. Acromag Representative Name: Title: Email: Office Phone: Office Fax: Russ Nieves Sales and solutions@acromag.com 248-295-0310 248-624-9234 Marketing Acromag, Inc. Tel: 248-295-0310 - 68 - - 68 - https://www.acromag.com...

  • Page 70: Revision History

    07 DEC 2020 ENZ/AMM Updated MTBF Numbers for AP482E-LF and added MTBF Tables for AP483E-LF and AP484E-LF. 10 MAR 2021 LMP/AMM Removed “50-Pin” in reference to the Front Panel Connector. Acromag, Inc. Tel: 248-295-0310 - 69 - - 69 - https://www.acromag.com http://www.acromag.com...
