- Page 1 IPES/IES-5416DF IPES/IES-5216DF Series 16 10/100TX + 4 or 2 100/1000FX Dual Speed Fiber L2 (w/ PoE at/af) EN50155 Managed Ethernet Switch User Manual (Hardware) IP-67 IP-54 Apr 2019...
- Page 2 Recommendation for Shielded network cables STP cables have additional shielding material that is used to reduce external interference. The shield also reduces the emission at any point in the path of the cable. Our recommendation is to deploy an STP network cable in demanding electrical environments. Examples of demanding indoor environments are where the network cable is located in parallel with electrical mains supply cables or where large inductive loads such as motors or contactors are in close vicinity to the camera or its cable.
- Page 3 Lantech Communications Global Inc. Products offered may contain software which is proprietary to Lantech Communications Global Inc. The offer or supply of these products and services does not include or infer any transfer of ownership.
- Page 4 FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.
-
Page 5: Table Of Contents
Content Chapter 1 Introduction ........... 5 Chapter 2 Hardware Description......6 Physical Dimension ........6 IP Protection ..........12 LED Indicators ..........15 Chapter 3 Hardware Installation ......17 Chapter 4 Network Application ......22 4.1 ITU G.8032 Scheme........22 4.2 Ring Coupling ..........22 4.3 Multiple Rings ..........23 4.4 Dual Homing ..........24 4.5 Chain ............24... -
Page 6: Chapter 1 Introduction
IPES-5216DF series 16 10/100TX PoE at/af + 2 Dual Speed Fiber L2 EN50155 Managed IP67/IP54 Ethernet Switch w/ 8 or 16 PoE at/af IES-5416DF series 16 10/100TX PoE at/af + 4 Dual Speed Fiber L2 EN50155 Managed IP67/IP54 Ethernet Switch... -
Page 7: Chapter 2 Hardware Description
Chapter 2 Hardware Description In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling information, and wiring installation. 2.1 Physical Dimension IPES-5416DF Aluminum case. IP-67, 285 (W) x 193 (D) x 91.2 (H) mm Aluminum case. IP-54, 252 (W) x 179.5 (D) x 91 (H) mm... - Page 8 IES-5416DF Aluminum case. IP-67, 285 (W) x 193 (D) x 91.2 (H) mm...
- Page 9 Aluminum case. IP-54, 252 (W) x 179.5 (D) x 91 (H) mm...
- Page 10 IPES-5216DF Aluminum case. IP-67, 285 (W) x 201.4 (D) x 84.4 (H) mm Aluminum case. IP-54, 285 (W) x 201.4 (D) x 84.4 (H) mm...
- Page 11 IES-5216DF Aluminum case. IP-67, 285 (W) x 201.4 (D) x 84.4 (H) mm...
- Page 12 Aluminum case. IP-54, 285 (W) x 201.4 (D) x 84.4 (H) mm...
-
Page 13: Ip Protection
Front panel of IPES-5416DF 2.2 IP Protection The IP Code, Ingress Protection Rating, sometimes also interpreted as International Protection Rating, classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water in mechanical casings and with electrical enclosures. - Page 14 The first digit indicates the level of protection that the enclosure provides against access to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid foreign objects. Object size Level Effective against protected against — No protection against contact and ingress of objects Any large surface of the body, such as the back of a >50 mm hand, but no protection against deliberate contact...
- Page 15 Dripping Dripping water (vertically Test duration: 10 minutes water falling drops) shall have no Water equivalent to 1 mm harmful effect. rainfall per minute Dripping Vertically dripping water Test duration: 10 minutes water when shall have no harmful effect Water equivalent to 3 mm tilted up to when the enclosure is tilted rainfall per minute...
-
Page 16: Led Indicators
water under defined 15 cm measured at top of conditions of pressure and device time (up to 1 m of submersion). Immersion The equipment is suitable Test duration: continuous beyond 1 m for continuous immersion in immersion in water water under conditions Depth specified by which shall be specified by manufacturer... - Page 17 The switch is not owner switch Power 1 is active PWR1 Green Power 1 is inactive Power 2 is active PWR2 Green Power 2 is inactive Power or port failure FAULT No failure A network device is detected. The port is transmitting or receiving packets Lnk/Act Blinking from the TX device.
-
Page 18: Chapter 3 Hardware Installation
Chapter 3 Hardware Installation 3.1Hardware installation 3.1.1Unpack switch and check the accessory with packing list 3.1.2 Mount the switch on desired position 3.1.3 Connect the M23/M12 connector of power input. Voltage of Power Input 12V model: Non-PoE model (5-pin M12 The power input voltage can be from connector) 9V to 60VDC... - Page 19 50.4V to 90VDC to feed power on both 802.3af/at standardized devices. 110V model: The power input voltage can be from 43V to 137.5VDC to feed power on both 802.3af/at standardized devices. Make sure that the external power supply unit you use to provide the PoE voltage fulfils the following basic criteria: ...
- Page 20 report a power failure. You can disable this power fail event via web browser. Pin assignment of alarm relay A break in contact is reported via the relay contact : The failure of at least one of the two supply voltages. ...
- Page 21 Ground screw 3.1.5 Connect the M12 connector with RJ-45 data cable, ports are not used shall be caped that comes with the package to insulate the surrounding.
- Page 22 Pin assignment of M12 10/100Tx network connector 3.1.6 Check the status of LED, make sure the switch was in working status. Note: The protection class IP67/IP54 is only achieved when bolted together. The other components attaching to the system have to meet with the IP67/IP54 protection class in order to reach the whole system IP67/IP54 protection.
-
Page 23: Chapter 4 Network Application
Chapter 4 Network Application 4.1 ITU G.8032 Scheme LANTECH G.8032 protocol is following ITU (International Telecommunication Unit) G.8032 v2 draft. The benefits of G.8032 are: 1. <50ms recovery time when failover 2. G.8032 has defined the protocol scheme, parameters, functions, test measures to be unified that the users can evaluate the possible network infrastructure without literally testing each brand in large scale. -
Page 24: Multiple Rings
4.3 Multiple Rings... -
Page 25: Dual Homing
4.4 Dual Homing 4.5 Chain... -
Page 27: Chapter 5 Console Management
Chapter 5 Console Management 5.1 Connecting to the Console Port The supplied cable which one end is M12 5-pole connector and the other end is RS- 232 connector. Attach the end of RS-232 connector to PC or terminal and the other end of M12 connector to the console port of the switch. - Page 28 The settings of communication parameters Having finished the parameter settings, click ‘OK’. When the blank screen shows up, press Enter key to have the login prompt appears. Key in ‘admin’ (default value) for both User name and Password (use Enter key to switch), then press Enter and the Main Menu of console management appears.
