- Page 1 IPES/IES-5416T Series 16 10/100TX + 4 1000T L2 (w/8 or 16 PoE at/af) EN50155 Managed Ethernet Switch User Manual (Hardware) IP-67 IP-54 Aug. 2023...
- Page 2 Recommendation for Shielded network cables STP cables have additional shielding material that is used to reduce external interference. The shield also reduces the emission at any point in the path of the cable. Our recommendation is to deploy an STP network cable in demanding electrical environments. Examples of demanding indoor environments are where the network cable is located in parallel with electrical mains supply cables or where large inductive loads such as motors or contactors are in close vicinity to the camera or its cable.
- Page 3 Lantech Communications Global Inc. Products offered may contain software which is proprietary to Lantech Communications Global Inc. The offer or supply of these products and services does not include or infer any transfer of ownership.
- Page 4 FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.
-
Page 5: Table Of Contents
Content Chapter 1 Introduction ..........5 Chapter 2 Hardware Description ......6 Physical Dimension ........6 Front Panel ............. 7 Package Content:........... 8 IP Protection ........... 9 LED Indicators..........12 Chapter 3 Hardware Installation ......14 Chapter 4 Console Management ......22 4.1. -
Page 6: Chapter 1 Introduction
Chapter 1 Introduction Lantech IES-5416T & IPES-5416T-8/16 (IP67/IP54) series is a high performance L2 IP67/IP54 industrial Gigabit uplink switch with 8x10/100TX + 4 10/100/1000T (w/8 or 16 PoE at/af injectors: IPES models) by M12 connectors which provides L2 wire speed and... -
Page 7: Chapter 2 Hardware Description
Chapter 2 Hardware Description In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling information, and wiring installation. A battery is inside the device to maintain the RTC function with estimated battery life of 10 years. The lost of battery power will only effect the RTC function. *Unless otherwise specified. -
Page 8: Front Panel
2.2 Front Panel PoE model... -
Page 9: Package Content
Non-PoE model 2.3 Package Content: Ethernet switch Console cable Manual CD (by request) -
Page 10: Ip Protection
2.4 IP Protection The IP Code, Ingress Protection Rating, sometimes also interpreted as International Protection Rating, classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water in mechanical casings and with electrical enclosures. It is published by the International Electrotechnical Commission (IEC) Solid particle protection The first digit indicates the level of protection that the enclosure provides against access... - Page 11 Liquid ingress protection The second digit indicates the level of protection that the enclosure provides against harmful ingress of water. Protected Level Testing for Details against — — protected Dripping Dripping water (vertically Test duration: 10 minutes water falling drops) shall have no Water equivalent to 1 mm harmful effect.
- Page 12 Powerful Water projected in powerful Test duration: at least water jets jets (12.5 mm nozzle) 3 minutes against the enclosure from Water volume: 100 litres per any direction shall have no minute harmful effects. Pressure: 100 kPa at distance of 3 m Immersion Ingress of water in harmful Test duration: 30 minutes...
-
Page 13: Led Indicators
2.5 LED Indicators The diagnostic LEDs that provide real-time information of system and optional status are located on the front panel of the industrial switch. The following table provides the description of the LED status and their meanings for the switch. Color Status Meaning... - Page 14 The port is transmitting or receiving packets Blinking from the TX device. No device attached.
-
Page 15: Chapter 3 Hardware Installation
For POE models: Do not use units’ POE ports to uplink to another POE switch in vehicle applications. (May Cause Damage) Lantech strongly advise the installation of a Galvanic isolated DC/DC converter between the power supply and the Ethernet switch on all Non-Isolated models. - Page 16 16.8V to 56VDC with galvanic isolation WV model: 16.8V to 137.5VDC WVI model: 16.8V to 137.5VDC with galvanic isolation PoE model 24V model: 9V to 36VDC 24VI model: 9V to 36VDC with PoE galvanic isolation 24TVI model: 16.8V to 56VDC with PoE galvanic isolation WV model: 16.8V to 137.5VDC...
- Page 17 M12 power connector M23 power connector Pin assignment of Power input Dual Power Input The power input can be supported redundantly. The supply voltage is electrically isolated from the housing. Note: With single power supply of the mains voltage, the device will report a power failure.
- Page 18 Pin assignment of alarm relay A break in contact is reported via the relay contact : The failure of at least one of the two supply voltages. The break link status of at least one switch port. 3.1.4 Fitting the device, grounding Install the system in a dry and clean area to protect the switch to get exposed with dirt.
- Page 19 Ground screw of Ethernet switch Ground – IP54 model The chassis is grounded via a separate grounding nut (M6). Use toothed locking washers for a good electrical connection. *Note: The torque should not be over 14 kilogram-force centimeter (kgf·cm). Using torque over 14 kgf·cm may cause damage to the grounding parts.
- Page 20 Pin assignment of M12 10/100Tx network connector...
- Page 21 Pin assignment of M12 10/100/100T network connector (A-coded) Pin assignment of M12 10/100/100T network connector (X-coded) 3.1.6 Check the status of LED, make sure the switch was in working status. Note: The protection class IP67/IP54 is only achieved when bolted together. ...
- Page 22 protection. Empty ports must be sealed with the protective caps supplied.
-
Page 23: Chapter 4 Console Management
Chapter 4 Console Management 4.1. Connecting to the Console Port The supplied cable which one end is M12 5-pole connector and the other end is RS-232 connector. Attach the end of RS-232 connector to PC or terminal and the other end of M12 connector to the console port of the switch. - Page 24 The settings of communication parameters Having finished the parameter settings, click ‘OK’. When the blank screen shows up, press Enter key to have the login prompt appears. Key in ‘admin’ (default value) for both User name and Password (use Enter key to switch), then press Enter and the Main Menu of console management appears.
