Dual Monitor Desk Stand
Instruction Manual
SKU: STAND-V002F/FW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-V002FW
Summary of Contents for Vivo STAND-V002FW
- Page 1 Dual Monitor Desk Stand Instruction Manual SKU: STAND-V002F/FW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Install the pole (A) to the base (B) using M6x16 Screw (S-A). Tighten with the 3mm Allen Wrench (T-A). STEP 2 Slide Pole Cable Clip (G) and Swivel Arm (C) down onto the Pole (A) and tighten the screw with 5mm Allen Wrench (T-B). - Page 4 STEP 3 OPTION A: Flat Back Monitor Attach the VESA Plates (D) to the monitors using M4x12mm Thumbscrew (M-A). NOTE: Hand tighten screws to avoid stripping the plastic screw heads. OPTION B: Curved Back Monitor Attach the VESA Plates (D) to the monitors using M6 Spacers (M-C) and M4x30mm Screws (M-B). Tighten with a Phillips screwdriver.
-
Page 5: Cable Management
STEP 4 Slide the monitors onto the heads of swivel arm and install the Security Nuts (S-B). Make sure the security nuts are installed before you rotate the monitors. Note: To prevent tipping, have a second person hold down the opposite arm to the one you are placing the monitor on. - Page 6 Adjust as Desired Tighten the bolt on the side of the tilt joint with the 5mm Allen Wrench (T-B) to fix the tilt angle. To level the monitors, remove the security nut and turn the bolt with the 3mm Allen Wrench (T-A) to raise or lower the monitor.
- Page 7 WARNING! CAUTION To prevent tipping, please be careful not to extend the arms beyond arrow range. SCREEN WEIGHT MUST BE CENTERED FOR STAND TO REMAIN BALANCED...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
