BACnet Server – Modbus Client

2 Protocol Implementation Conformance Statement

BACnet Protocol Implementation Conformance Statement (PICS)
Date: 2018-05-16
Vendor Name: HMS Industrial Networks S.L.U
Product Name: INBACMBM---0000
Product Model Number: INBACMBM---0000
Application Software Version: 1.1.4.0
Firmware Revision: 14.1.2.0
BACnet Protocol Revision: 14
Product Description:
Modbus – BACnet MS/TP & BACnet IP Gateway
Abstraction of Modbus Registers as BACnet Objects.

BACnet Standardized Device Profile (Annex L):

BACnet Operator Workstation (B-OWS)
BACnet Building Controller (B-BC)
BACnet Advanced Application Controller (B-AAC)
BACnet Application Specific Controller (B-ASC)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
Additional BACnet Interoperability Building Blocks Supported (Annex K):
Reference of BIBBs List

Segmentation Capability:

Segmented request supported
Segmented responses supported

Data Link Layer Options:

BACnet IP, (Annex J)
BACnet IP, (Annex J), Foreign Device
ISO 8802-3, Ethernet (Clause 7)
ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 57600, 76800, 115200
MS/TP slave (Clause 9), baud rate(s):
Point-To-Point, EIA 232 (Clause 10), baud rate(s):
Point-To-Point, modem, (Clause 10), baud rate(s):
LonTalk, (Clause 11), medium: _____
Other:
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
No Yes Window Size · 16
No Yes Window Size · 16
