BACnet Server – Modbus Client

5.2.5 Binary Input Object Type

Property Identifier
Object_Identifier
Object_Name
Object_Type
Present_Value
Description
Status_Flags
Event_State
Reliability
Out_Of_Service
Polarity
Inactive_Text
Active_Text
Time_Delay
Notification_Class
Alarm_Value
Event_Enable
Acked_Transitions
Notify_Type
Event_Time_Stamps
Event_Detection_Enable
Property_List
1
Only available when specific object has a Notification Class configured
2
Only available in some models after activations on the configuration tool, review the specific model manual for
details
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Property Datatype
BACnetObjectIdentifier
CharacterString
BACnetObjectType
BACnetBinaryPV
CharacterString
BACnetStatusFlags
BACnetEventState
BACnetReliability
BOOLEAN
BACnetPolarity
CharacterString
CharacterString
Unsigned
Unsigned
BACnetBinaryPV
BACnetEventTransitionBits -
BACnetEventTransitionBits -
BACnetNotifyType
BACnetArray[N] of
BACnetTimeStamp
BOOLEAN
BACnetARRAY[N] of
BACnetPropertyIdentifier
Value
(Binary Input, 0)
Configurable through Config Tool
BINARY_INPUT (3)
INACTIVE (0) / ACTIVE (1)
Configurable through Config Tool
{FALSE, FALSE/TRUE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0),
UNRELIABLE_OTHER (7)
FALSE
NORMAL (0)
Configurable through Config Tool
Configurable through Config Tool
-
-
-
-
-
-
-
User Manual r1.10 eng
ASHRAE IBOX
R R
R R
R R
R R
2
O R
R R
R R
O R
R R
R R
O R
O R
1
O R
1
O R
1
O R
1
O R
1
O R
1
O R
1
O R
O R
R R
