7. Symbols Glossary
Following are the symbols and their descriptions used in
the MAXFRAME AUTOSTRUT System:
Symbol Standard Number
and Title
EN ISO 15223-1
EN ISO 15223-1
ISO 15223-1
21 CFR 801.109
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
ISO 15223-1
50 Physician User Manual • MAXFRAME AUTOSTRUT™ System
Symbol Symbol Title
Number
5.1.5 Batch code
5.1.7 Serial number
5.1.3 Date of manufac-
ture
– Prescription Use
Only
5.4.2 Do not reuse
5.4.4 Caution
5.4.3 Consult instructions
for use
5.1.6 Catalog number
5.1.1 Manufacturer
5.3.7 Temperature limit
5.3.9 Atmospheric pres-
sure limitation
5.2.8 Do not use if pack-
age is damaged
5.7.10 Unique Device
Identifier
(Barcode)
Description
Indicates the manufacturer's batch code so that
the batch or lot can be identified.
Indicates the manufacturer's serial number so
that a specific medical device can be identified.
Indicates the date the device was manufac-
tured.
Caution: Federal (US) law restricts this device
to sale by or on the order of a physician.
Indicates a medical device that is intended
for one use, or for use on a single user during
a single procedure.
Indicates the need for the user to consult the
instructions for use for important cautionary
information such as warnings and precautions
that cannot, for a variety of reasons,
be presented on the medical device itself.
Indicates the need for the user to consult the
instructions for use.
Indicates the manufacturer's catalog number
so that the medical device can be identified.
Indicates the medical device manufacturer.
Indicates the temperature limits to which the
medical device can be safely exposed.
Indicates the range of atmospheric pressure
to which the medical device can be safely
exposed.
Indicates a medical device that should not
be used if the package has been damaged or
opened.
Indicates a carrier that contains Unique Device
Identifier information.
