- Page 1 Cimarec Ceramic Top ® Stirring Hot Plates, Stirrers, and Hot Plates OPERATION MANUAL AND PARTS LIST 4” x 4” (10cm x 10cm) HP194515 Hot Plate S194615 Stirrer SP194715 Hot Plate Stirrer 7” x 7” (18cm x 18cm) HP194825 Hot Plate S194925 Stirrer SP195025 Hot Plate Stirrer LTM1950X1 •...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..............................3 Warnings ................................3 Operation ................................6 Introduction ..............................6 Setting Heating Temperature ..........................6 Setting Stirring Speed ............................6 Specifications ..............................7 4" x 4" Models ..............................7 7" x 7" Models ..............................8 Replacement Parts Listings ..........................9 Hot Plates ................................9 Stirrers................................9 Stirring Hot Plates ............................9 Ordering Information ............................10 Warranty ................................11... -
Page 3: Safety Information
Safety Information Your Thermo Scientific Cimarec Hot Plate, Stirrer or Stirring Hot Plate has been designed with function, reliabili- ty, and safety in mind. It is your responsibility to install it in Alert Signals conformance with local electrical codes. This manual con- tains important operating and safety information. - Page 4 AFETY NFORMATION may result. Unit contains components which may ignite such materials. “Caution: Hot Surface. Avoid Contact.” The top plate will remain hot without visual indication for some time after the unit has been turned off. Keep the top surface clean. Use a non-abrasive cleaner.
- Page 5 AFETY NFORMATION Warning THIS PRODUCT CONTAINS REFRACTORY CERAMIC, REFRACTORY CERAMIC FIBER OR FIBERGLASS (GLASS WOOL) INSULATION WHICH CAN PRODUCE RESPIRABLE FIBERS AND DUST WHEN HANDLED. THESE FIBERS OR DUSTS CAN CAUSE IRRITATION AND CAN AGGRAVATE PRE—EXISTING RESPIRATORY DISEASE. REFRACTORY CERAMIC INSULATIONS MAY CONTAIN OR MAY FORM CRYSTALLINE SILICA (CRYS- TOBALITE) WHICH MAY CAUSE LUNG DAMAGE (SILI- COSIS).
-
Page 6: Operation
Operation Introduction Your general purpose heating and/or stirring devices are intended for general laboratory procedures. A vessel with a flat bottom is recommended on the hot plate and stirring hot plate for ideal heat transfer. Avoid metal containers, sand- baths or vessels with a rim around the bottom as these could cause damage to the hot plate and stirring hot plate. -
Page 7: Specifications
Specifications 4” x 4” Models Model Numbers HP194515 S194615 SP194715 Overall Dimensions in. (cm) Width 5.7 (14.5) 5.7 (14.5) 5.7 (14.5) Height 5.0 (12.7) 5.0 (12.7) 5.0 (12.7) Depth 7.9 (20) 7.9 (20) 7.9 (20) Top Plate dimensions in. (cm) 4.25 x 4.25 (11 x 11) 4.25 x 4.25 (11 x 11) 4.25 x 4.25 (11 x 11) Weight Lbs. -
Page 8: 7" X 7" Models
PECIFICATIONS 7” x 7” Models Model Numbers HP194825 S194925 SP195025 Overall Dimensions in. (cm) Width 8.3 (21.1) 8.3 (21.1) 8.3 (21.1) Height 5.1 (12.8) 5.1 (12.8) 5.1 (12.8) Depth 11.1 (28.2) 11.1 (28.2) 11.1 (28.2) Top Plate dimensions in. (cm) 7.25 x 7.25 (18.4 x 18.4) 7.25 x 7.25 (18.4 x 18.4) 7.25 x 7.25 (18.4 x 18.4) Weight Lbs. -
Page 9: Replacement Parts Listings
Replacement Parts Hot Plates 4x4 Part Number 7x7 Part Number Description 540-0033 710-0017 Top plate only ELX71 ELX74 Element CNX171 CNX171 Control (heat) CR1928X1 CR1928X1 Cord set, 120 volt Stirrers 4x4 Part Number 7x7 Part Number Description 540-0033 710-0017 Top plate only CN1928X1 CN1931X1 Control (speed) -
Page 10: Ordering Information
Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any correspon- dence concerning this unit. All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory. -
Page 11: Warranty
(ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts.
