HM Maine Coffee Table
Assembly Instructions
Dimensions
Width - 80cm
Depth - 40cm
Height - 45cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Please keep for future reference
-
806/4402
798/5362
792/8044
764/8070
797/9323
803/2276
Version 3 Date: 18/09/17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos HOME HM Maine 806/4402
Summary of Contents for Argos HOME HM Maine 806/4402
- Page 1 Width - 80cm Depth - 40cm Height - 45cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 3 Date: 18/09/17...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed on or put weight on the product, the likelihood of the following pages. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Top support (76.8 x 6cm) Top panel (80 x 40cm) Bottom support (76.8 x 6cm)
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. in some cases mor may be supplied than are required. 39mm Locking pin x 16 30mm Dowel x 8 15mm Locking nut x 16 15mm Screw x 12 Plastic support x 6 Tools required Phillips screwdriver...
- Page 5 Assembly Instructions Step Attaching bottom panel Use Screw to fix the Plastic supports onto the Bottom support Note: Be sure the edges of the Plastic supports even with the edges of Bottom support Position the Bottom supports onto the Bottom panel Screws Insert Dowels into the...
- Page 6 Assembly Instructions Step 2 Attaching side panel Screw Locking pins into the Side panel Note: Insert locking pins as far as shown. Do not over tighten. Insert Dowels into the Side panel Position Top supports onto the Side panel Insert Locking nut into the Top supports Use a screwdriver to turn Locking nut...
- Page 7 Assembly Instructions Step 2 - continued Position Bottom panel onto the Side panel Insert Locking nuts into the Bottom panel Use a screwdriver to turn Locking nut clockwise to lock. Position Side panel onto the unit. Insert Locking nuts into the Bottom panel and Top supports Use a screwdriver to turn Locking nut...
- Page 8 Assembly Instructions Step 3 Attaching top panel Screw Locking pins into the Top panel Note: Insert locking pins as far as shown. Do not over tighten. Position Top panel onto the unit. Insert Locking nuts into the Side panels , Top supports Use a screwdriver to turn Locking nut...
- Page 9 Note: to ask someone to help you at this stage. With help, place the unit in the intended position. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
