Mix and Match - 3 Door Robe

Assembly Instructions -

Dimensions

Width - 103cm

Depth - 50cm

Height - 167cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

709/2523

709/2516

709/0848

355/3743

MADE IN

BRITAIN

Issue 2 - 09/10/14

Need help?

Do you have a question about the Mix and Match 709/2523 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Mix and Match 709/2523

Page 1 Mix and Match - 3 Door Robe Assembly Instructions - 709/2523 Please keep for future reference 709/2516 709/0848 355/3743 Dimensions Width - 103cm Depth - 50cm MADE IN Height - 167cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 09/10/14...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 58kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D2020A) (999 x 492mm) Left Side Right Side Upright Base (D2021A) (D2022A) (D2023A)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the upright Tap 2 wooden dowels into the upright Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
Page 6 Assembly Instructions Step 4 Join the base and upright Push the base onto the upright secure with 2 screws Finished p l a i n c front edge h i p a r d s u r f a c Finished front edge Step 5...
Page 7 Assembly Instructions Step 6 Prepare the left side Push a rail holder into the left side . Make Finished sure that it is fitted front edge straight, in line with the panel edges and then secure with screw Fit 3 hinge plates onto the left side , making...
Page 8 Assembly Instructions Step 8 Fit the right side Push the right side onto the top base and secure with 4 screws Step 9 Prepare the plinth Tap 2 wooden dowels into the plinth...
Page 9 Assembly Instructions Step 10 Fit the plinth Push the plinth onto the right side secure with screw Step 11 Fit the left side Push the left side onto the assembly and secure with 5 screws...
Page 10 Assembly Instructions Step 12 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
Page 11 Assembly Instructions Step 13 Fit the hanging rail Push the hanging rail into the rail holders fitted to the right side and upright Step 14 Fit the shelves For each of the 2 shelves , insert 4 shelf studs at the required height.
Page 12 Assembly Instructions Step 15 Prepare the 2 outer doors Important: The 6 hinges used in this step are in the bag marked as AHP1546. Push fit 3 cranked hinges into 2 of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are...
Page 13 Assembly Instructions Step 17 Fit the 2 outer doors and their handles 2 people are needed here Note: The easiest way to attach each outer door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate...
Page 14 Assembly Instructions Step 18 Fit the centre door and its handle Note: The easiest way to attach the centre door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
Page 15 Assembly Instructions Step 19 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 16 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2842...
Page 17 Mix and Match - 3 Door Robe Assembly Instructions - 709/2523 Please keep for future reference 709/2516 709/0848 355/3743 Dimensions Width - 103cm Depth - 50cm MADE IN Height - 167cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 3 - 21/01/15...
Page 18 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 58kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 19 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D2020A) (999 x 492mm) Left Side Right Side Upright Base (D2021A) (D2022A) (D2023A)
Page 20 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 21 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the upright Tap 2 wooden dowels into the upright Note: Wooden dowels must not stick out from 10mm the edge by more than 10mm or they may...
Page 22 Assembly Instructions Step 4 Join the base and upright Push the base onto the upright secure with 2 screws Finished p l a i n c front edge h i p a r d s u r f a c Finished front edge Step 5...
Page 23 Assembly Instructions Step 6 Important: The 3 hinge plates used in this Prepare the left side step are in the bag marked as . . . 1546. Push a rail holder into the left side . Make sure that it is fitted straight, in line with the panel edges and then secure with screw...
Page 24 Assembly Instructions Step 8 Fit the right side Push the right side onto the top base and secure with 4 screws Step 9 Prepare the plinth Tap 2 wooden dowels into the plinth...
Page 25 Assembly Instructions Step 10 Fit the plinth Push the plinth onto the right side secure with screw Step 11 Fit the left side Push the left side onto the assembly and secure with 5 screws...
Page 26 Assembly Instructions Step 12 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
Page 27 Assembly Instructions Step 13 Fit the hanging rail Push the hanging rail into the rail holders fitted to the right side and upright Step 14 Fit the shelves For each of the 2 shelves , insert 4 shelf studs at the required height.
Page 28 Assembly Instructions Step 15 Important: The 6 hinges used in this step are in the bag marked as . . . 1546. Prepare the 2 outer doors Important: The 6 hinges used in this step are in the bag marked as .
Page 29 Assembly Instructions Step 17 Fit the 2 outer doors and their handles 2 people are needed here Note: The easiest way to attach each outer door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate...
Page 30 Assembly Instructions Step 18 Fit the centre door and its handle Note: The easiest way to attach the centre door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
Page 31 Assembly Instructions Step 19 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 32 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2842...

This manual is also suitable for:

Mix and match 709/2516 Mix and match 709/0848 Mix and match 355/3743
