Assembly Instructions
EXTENDED
Note: It will require two people to complete this assembly.
Before you
start, here
is some
helpful advice
1. We suggest you spend a short time reading through this leaflet and
then follow the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth
the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are
only finger tightened during initial assembly. Only upon completion
of the assembly should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure
they remain fully tightened.
7. Keep glue and fittings out of children's reach.
After-sales telephone number for spare parts : 08456 400800
CLOSED
Advertisement
Table of Contents
Related Manuals for Argos Single Metal Futon
Summary of Contents for Argos Single Metal Futon
- Page 1 Single Metal Futon Assembly Instructions CLOSED EXTENDED Note: It will require two people to complete this assembly. Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 Component parts and fittings contained in the box Parts QTY 1pc RIGHT QTY 2pcs LEFT QTY 1pc QTY 1pc QTY 1pc QTY 1pc (LEFT) (RIGHT) QTY 1pc QTY 1pc Fittings Ø QTY 4 QTY 4 16mm C QTY 12 15mm Washer 35mm QTY 4...
- Page 3 ASSEMBLY 1) Assemble left hand hinge ③ STEP 1 to left side frame ① u sing fixings Note: Both the hinge and frame are identified ！ 181mm 1) Assemble right hand hinge STEP 2 ④ to right side frame ② u sing fixings Note: Both parts are identified...
- Page 4 ASSEMBLY 1) Assemble rails ⑤ in STEP 3 between side frames ① and ② using fixings 1) Assemble support leg ⑦ STEP 4 the underside of main base panel using fixings ⑥...
- Page 5 ASSEMBLY 1) Assemble back panel ⑧ STEP 5 hinges using fixings 1) Open out main base panel STEP 6 ⑥ 2) Fold out the support foot by releasing the spring pin as shown . PUSH...
- Page 6 ASSEMBLY 1) Assemble base panel ⑥ STEP 7 the hinges using fixings 2) Stick self adhesive foam pads o nto rails ⑤ at the base frame contact points.
- Page 7 ASSEMBLY TO OPEN STEP 8 1) Lift the front edge of the seat section. 2) Push the back section down until both sections are flat. 3) By depressing the release pin, fold down the support foot. 4) Open out the folding seat. 5) Extend the support leg.
- Page 8 Single Metal Futon Assembly Instructions 656/0881 – Please keep for future reference Dimensions Extended Closed Width - 192.5cm Width - 88cm Depth - 88cm Depth - 89cm Height - 30cm Height - 74cm Important – Please read these instructions fully before starting assembly...
- Page 9 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Keep hands clear of the hinge • Legs can be folded away for components and tools listed on folding area when opening or flat storage.
- Page 10 Components - Parts Please check you have all the parts listed below Left side frame Left hand hinge (84 x 30cm) (47 x14.5cm) Right side frame Right hand hinge (84 x 30cm) (47 x 14.5cm) Side rail x 2 (80.6 x 4cm) Back frame (75 x 62cm) 7 Seat frame...
- Page 11 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 12 Assembly Instructions Step 1 Assembling hinges Place side frames flat onto the floor with the labels facing upwards. Back Assemble left hand hinge to left side frame using fixings Front Note: Both the hinge and frame are identified Assemble right hand hinge to right side frame...
- Page 13 Assembly Instructions Step 3 Assembling back frame Assemble back frame to the hinges using fixings Step 4 Assembling support legs Assemble support leg to the underside of seat frame using fixings...
- Page 14 Assembly Instructions Step 5 Open out seat frame Open out seat frame Fold out the support foot by releasing the spring pin as shown. PUSH Step 6 Assembling seat frame Assemble seat frame to the hinges using fixings Stick self adhesive foam pads onto rails as shown.
- Page 15 Assembly Instructions Step 7 TO OPEN 1) From the front corner of the seat frame, raise the seat frame slightly. 2) At the same time, push the back frame down until both frames are flat. 3) Press the release pin on the support foot and fold down until it clicks into position.
