Mix and Match - Chests

Assembly Instructions -

Chest

Dimensions

Width - 75cm

Depth - 36cm

Height - 57.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

Bedside

Dimensions

Width - 38.5cm

Depth - 36cm

Height - 41.5cm

709/0219

709/2482

709/2475

MADE IN

BRITAIN

Issue 2 - 11/12/12

Need help?

Do you have a question about the Mix and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Mix

Page 1 Mix and Match - Chests Assembly Instructions - 709/0219 Please keep for future reference 709/2482 709/2475 Chest Bedside Dimensions Dimensions Width - 75cm Width - 38.5cm Depth - 36cm Depth - 36cm MADE IN Height - 57.5cm Height - 41.5cm...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: These units weigh • Make sure you have enough • We do not approximately 21kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below 1 Door Bedside (follow steps 1 to 14) Left Side Right Side 4 Plinth (D0888A)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 If you would If you would Choose which way like your door like your door you would like the to open this to open this door to open...
Page 6 Assembly Instructions Step 4 Prepare the base Tap 2 wooden dowels into the base Step 5 Plain chipboard surface Prepare the plinth Tap 2 wooden dowels into the plinth Step 6 Fit the base and plinth to the right side Push the base onto the right side...
Page 7 Assembly Instructions Step 7 Fit the left side Push the left side onto the assembly and secure it using 3 screws Step 8 Prepare the top Screw 2 metal dowels into the holes on the top Note: Tighten metal dowels up fully against the panels.
Page 8 Assembly Instructions Step 10 Fit the back The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
Page 9 Assembly Instructions Step 12 Fit door and handle Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 10 Assembly Instructions Step 13 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 11 Assembly Instructions Step 15 Prepare the drawer fronts and wraps Screw 2 metal dowels into the holes shown on the back of the drawer fronts Note: Tighten metal dowels up fully against the panel. Insert 2 small locking nuts into the holes shown on the drawer wraps Note: Due to the manufacturing process,...
Page 12 Assembly Instructions Step 17 Push the drawer stops into the 3 large drawer wraps Carefully break off the 2 drawer stops (F599) from each pair of the drawer runners Push the drawer stops fully through the large drawer wraps from the inside.
Page 13 Assembly Instructions Step 19 Prepare the left and right sides F600 10mm Separate runners Push fit 3 left runners marked ‘L’ into the holes shown on left side Note: Runners must be be fitted flat against the panel. If necessary Finished gently tap into final front edge...
Page 14 Assembly Instructions Step 20 Prepare the 2 plinths Plain chipboard surface Tap 2 wooden dowels into each plinth Step 21 Fit the plinths to the sides Attach the 2 plinths to the left side right side using the dowels already fitted and secure with screws Step 22...
Page 15 Assembly Instructions Step 23 Fit the top Push the top onto the side panels Use a screwdriver to tighten the 2 large locking nuts fitted to the inside of the side panels Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Page 16 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2787...
