Ø1/2" Shutters and Controller
Ø0.5" 5-Bladed
Aperture
Ø0.5" 5-Bladed
Aperture
Rev F, December 9, 2018
SHB05 Shutter Head, Front
SHB05T Shutter Head, Front
Figure 3 Shutter Head Front and Rear Views
Chapter 3: Description
Ø0.07" Mounting
Through Holes, 3 Places
SM05 Thread
(0.535"-40)
SHB05 Shutter Head, Rear
Ø0.07" Mounting
Through Holes, 3 Places
SM05 Thread
(0.535"-40)
SHB05T Shutter Head, Rear
