Chapter 6 Interface Connector - THORLABS SHB05 User Manual

Ø1/2" Shutters and Controller
Chapter 6
The interface connector on the SHB05(T) controller is a 4-pin mini-DIN shielded
female connector that accepts the 4 pin mini-DIN male connector.
The pin descriptions are as follows:
Page 16
Interface Connector
Pin
1
2
3
4
SHIELD
1
3
Figure 6 SHB05(T) Controller Pin-Out
2
4
Figure 7 SHB05(T) Shutter Pin-Out
Chapter 6: Interface Connector
Description
Shutter Detect
Modulation +
+5 VDC
Modulation -
GND
2
4
1
3
