MUNBYN ITPP941 - Logistics Label Printer Manual

PRODUCT INTRODUCTION

What's in the box?

1. Printer
2. MAC Adapter
3. Alcohol Pad
4. USB Flash drive
5. USB Cable
6. Power Adapter
7. Power Cable
8. After-sale Card
9. Card
10. Labels
11. User manual

QUICK PRINTER INSTALLATION

Note: Please use the power adapter provided by MUNBYN.

LABEL SETUP

1. Facing the front of the printer, press the cover open button to open the top cover.
2. Install the label paper with the holders on both sides.
3. Finish the label paper installation, and then close the cover.
4. For new label paper, do the label size calibration again.

Note: Before using the printer to print labels, please calibrate the paper size.

Label size calibration:

1. Turn on the printer.
2. Press FEED button and hold on.
3. Release the button when you hear one 'Di' sound.
4. Then, the printer will calibrate the label size.

DRIVER INSTALLATION

Support downloading driver files via USB flash drive or download link.

Printer driver download link: https://munbyn.biz/941d

Tutorial video:

For Windows: https://munbyn.biz/941win
For Mac OS: https://munbyn.biz/941mac

Printer head (TPH) will be very hot after printing, Please do not touch the printer head or parts around it.

WINDOWS DRIVER INSTALLATION

Note: Please connect to the computer first and then turn on the printer.

1. Open the driver software you downloaded.

2. Click on "Install" to start installing the driver.

3. Follow the guideline to install until "Finish" appears, then we can use our printer to print shipping labels.

4. Set the printer paper size.

5. Choose 100×150mm(4x6") label size and apply, then we can use our printer to print shipping labels.


MAC DRIVER INSTALLATION

Note: Please connect to the computer first and then turn on the printer.

1. Open the driver software you downloaded.

2. Start installation.

3. Follow the guideline to install until "The installation was successful appears".

4. Add printer in printer list.


5. Choose printer and "Select Software".



6. Page Setup, choose 4x6" (100x150 mm), then we can open the document and select the printer to print shipping labels.


"FEED" BUTTON INSTRUCTION

LED STATUS

FAQ

Q1: When the printing is too faint, how to adjust the density and printing speed?

A1: For Windows: Printer Preferences → Page Setup → Setting
For Mac OS: Can be set in drop-down menu under 'Printer Features'

Tutorial video: https://munbyn.biz/941dsv

Q2: What can I do if paper is jammed or there are white spots in my print?

A2: Turn off the printer, and allow the printer head to cool down. Use the pad with alcohol to wipe the printer head clean.

Tutorial video: https://munbyn.biz/941pjv

Q3: Why the printer is skipping labels or continuously feeding?

A3: Make sure your computer does not send a print command to ITPP941, disconnect the USB cable, and then run the automatic label identification function.

Tutorial video: https://munbyn.biz/941cfv

Q4: Why the printer print extra blank labels after the one successful print?

A4: Please check if the paper size setting of the printer is correct and adjust the scale and margins in preview page or page setup when you are printing from browser.

Tutorial video: https://munbyn.biz/941obv

Q5: Why I am printing blank labels?

A5: Make sure your labels are 'Direct Thermal' labels and the label that you peel off should be facing the ceiling when it comes out of the printer.

Tutorial video: https://munbyn.biz/941pbv

Q6: How can we print the label that is not in standard 4*6 inch, such as the USPS?

A6: You can use the screenshot to print the label in correct size.

Tutorial video: https://munbyn.biz/941arv

Q7: How to print self-test label?

A7: The self-test label can be used to determine whether the machine is malfunctioning and whether the printing performance is good. You can print self-test label as follows.

1. Turn on the printer.
2. Press FEED button and hold on.
3. Release the button when you hear two 'Di' sound.

FAQ download link: https://munbyn.biz/941faq

SPECIFICATIONS

SUPPORT

Need Tech Support, contact us by:

WhatsApp
+8617817881067

FB message
Munbynofficial

E-mail: support@munbyn.com

Whatsapp: +8617817881067

Skype: munbyn

Support time: Monday to Friday 24 hours.

Version: 2.0.1
