SILVERLEAVES 3 PCE RESIN WICKER BENCH SETTING
A
Table leg
B
Table frame
C
Support Bracket
D
M6x20
E
M6x35
F
Bolt cover
G
Washer
H
Allen Key
I
Glass
Assembly Instruction
Item number:3192437
1
2
4
16
4
16
20
1
1
Step 1:
Secure the table frame (B) to the table legs (A),
using the bolt (D),washer(G), bolt cover(F)and Allen key(H).
C
B
A
B
A
Step 2:
Use the support bracket (C) to secure the table
F
frame (B) with the table legs (A), using bolt (D),
G
washer (G), allen key (H) and bolt cover (F).
D
F
G
D
Repeat for each leg.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mimosa Signature Silverleaves 3192437
Summary of Contents for Mimosa Signature Silverleaves 3192437
- Page 1 SILVERLEAVES 3 PCE RESIN WICKER BENCH SETTING Assembly Instruction Item number:3192437 Table leg Table frame Support Bracket M6x20 M6x35 Bolt cover Washer Allen Key Glass Step 1: Secure the table frame (B) to the table legs (A), using the bolt (D),washer(G), bolt cover(F)and Allen key(H). Repeat for each leg.
- Page 2 Step 3: Use scissors to carefully cut and remove the strapping securing the glass in place. Step 4: Carefully lift the glass top and place on a clean protected surface.
- Page 3 Step 5: Using the bolt(E) ,washer(G) with the shaft sleeve,secure with the table frame(A)and leg frame(B),and using the allen key (H). Carefully replace the glass (I) back on top of the table frame (A). Step 6: Your table is now fully assembled and ready for use. Step 7: Important Notice: Do not fully tighten bolts until the table is fully assembled.
- Page 4 Bench frame Bench leg Support bracket M6x20 Washer Bolt cover Allen key Adjusting knob Secure the bench frame (A) to the bench legs (B), Step 1: using bolt (D), washer (E), bolt cover (F) and allen key (G). Repeat for the other leg. Step 2: Use the support bracket(C) to secure the bench frame (A) to the bench legs(B), using bolt (D), washer (G),...
