LOUNGE STEEL
HELSINKI RATTAN 2 SEAT
ASSEMBLY INSTRUCTIONS
Item No. 0352936
!
READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY
1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED.
2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR.
3. ASSEMBLE STEP BY STEP FOLLOWING THE INSTRUCTIONS.
4. WASHERS MUST BE USED.
5. DURING ASSEMBLY DO NOT OVER FASTEN SCREWS & NUTS.
6. DO NOT COMPLETELY TIGHTEN EACH SCREW AND NUT UNTIL THEY ARE ALL FIXED IN PLACE.
6-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 0352936 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mimosa 0352936

  • Page 1 LOUNGE STEEL HELSINKI RATTAN 2 SEAT ASSEMBLY INSTRUCTIONS Item No. 0352936 READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY 1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED. 2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR.
  • Page 2: Parts List

    PARTS LIST PARTS QTY. CODE Seat Top Seat Base Seat Cushion 2PCS Pillow Clip 4PCS...
  • Page 3: Hardware List

    HARDWARE LIST CODE PARTS QTY. Bolt - M6x70 4PCS Bolt - M6x55 4PCS Bolt - M6x20 2PCS Washer 16PCS 6PCS Allen Key Wrench 10PCS 6PCS...
  • Page 4 Use Allen Key (F) and wrench (G) to fix seat top (#1) to seat base (#2) with bolt and nut (A&E) and washers (D). Cover with caps (H&I). Use Allen Key (F) and wrench (G) to fix chair legs (#3&#4) as picture with bolt and nut (B&E) and washers (D) and clip (#7).
  • Page 5 Fix whole seat to leg (#4) with Allen key (F), bolt (B) and washer (D). Cover with cap (H). Loosely tighten the bolts until all bolts are in position. Repeat step 3 to fix front leg (#3). Once all bolts are in position securely tighten all bolts.
  • Page 6 Fasten seat cushion (#5) and pillows (#6) on chair with the fabric ties. And your chair is ready to use.
