Chair (A)x1
A
Use screws and washers (D) to fit the support bar (B) to the chair (A). Once all screws are in position
tighten securely using Allen key (E), then cap the screws. Complete the chair assembly by securing
the cushion (C). Repeat for all the chairs.
SILVERLEAVES 7 PCE RESIN
WICKER BAR SETTING
ASS EMBLY INSTRUCTIONS
PARTS LIST
Support Bar (B)x1
Cushion (C)x1
B
3192438
Cap,Screw and Washer (D)x6
Allen Key (E)x1
C
D
Advertisement
Related Manuals for Mimosa Signature Silverleaves 3192438
Summary of Contents for Mimosa Signature Silverleaves 3192438
- Page 1 SILVERLEAVES 7 PCE RESIN WICKER BAR SETTING ASS EMBLY INSTRUCTIONS 3192438 PARTS LIST Support Bar (B)x1 Cap,Screw and Washer (D)x6 Chair (A)x1 Cushion (C)x1 Allen Key (E)x1 Use screws and washers (D) to fit the support bar (B) to the chair (A). Once all screws are in position tighten securely using Allen key (E), then cap the screws.
- Page 2 SILVERLEAVES 7 PCE RESIN WICKER BAR SETTING ASSEMBLY INSTRUCTIONS 3192438 PARTS LIST Table Top (A)x1 Right Leg (B)x2 Use screws and washers(G) to fit the legs (B) and (C) to the table Left Leg (C)x2 top (A). Loosely tighten screws using Allen Key (H). Then attach the cross support bar (D) to the table legs (C&B), using screws and washers (G) and Allen Key (H).
