SILVERLEAVES 3-SEATER
RESIN WICKER SWING
ASSEMBLY INSTRUCTION
Item No. 3191962
!
READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY
1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED.
2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR.
3. ASSEMBLE STEP BY STEP FOLLOWING THE INSTRUCTIONS.
4. WASHERS MUST BE USED.
5. DURING ASSEMBLY DO NOT OVER FASTEN SCREWS & NUTS.
6. DO NOT COMPLETELY TIGHTEN EACH SCREW AND NUT UNTIL THEY ARE ALL FIXED IN PLACE.
8-1
Advertisement
Table of Contents
Related Manuals for Mimosa Silverleaves 3191962
Summary of Contents for Mimosa Silverleaves 3191962
- Page 1 SILVERLEAVES 3-SEATER RESIN WICKER SWING ASSEMBLY INSTRUCTION Item No. 3191962 READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY 1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED. 2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR. 3.
- Page 2 PARTS LIST PARTS LIST QTY. QTY. CODE PARTS CODE PARTS 2PCS 2PCS Short pole Foot tube 2PCS Long pole Left front tube 2PCS Spring hanger Right back tube Left back tube Right front tube Seat cushion Back tube 2PCS Canopy frame Beam Seat frame Canopy...
- Page 3 Attach two left tubes(#2&4) to the left foot tube, same steps with the right side. Using bolt(D) to attach the top beam(#7) Attach the back tube(#6) to the frame, to the frame. using bolt(E).
- Page 4 Attach long & short poles(#11&12) to the seat frame(#8), then secure right & left armrest(#9&10) to the seat frame(#8) as well, using bolt(A,B&C). Noted that the leak hole in poles should face inside. Attach poles(#11&12) to spring hangers(#13), then secure spring hangers to the beam(#7) to combine the two frame part.
- Page 5 Attach canopy frame(#15) to the whole bracket, using bolt(#17). Attach the canopy(#16) to the canopy frame,edges should be curled in to fix the canopy.
- Page 6 Attach seat cushion(#14) to the seat frame, using ties with it to secure. The main frame is now assembled at this stage. To improve the assembly of the canopy follow remaining steps below.
- Page 7 For left side of canopy: spin the rotary knob(#17) to Then adjust the canopy to right position. loose canopy. Pull canopy to the right angle as needed. Secure the rotary knob to fix the canopy.
- Page 8 For right side, follow same four steps below as doing with left side to secure canopy. Now your swing is ready for use. CARE AND CLEANING: Not For Commercial Use 1. TO CLEAN, WIPE WITH DAMP CLOTH. DO NOT USE BLEACH, ACID SOLVENTS OR ABRASIVE CLEANERS ON RESIN WICKER OR FRAME PARTS. 2.
