FOX3 Matrix Series • Setup Guide (Continued)
ATTENTION:
• Do not touch the electronic components or the connectors on the backplane or on the circuit boards without being
electrically grounded. Handle circuit boards by their edges only. Electrostatic discharge (ESD) can damage circuits,
even though you cannot feel, see, or hear it.
• Ne pas toucher les composants électroniques ou les connecteurs sur la carte mère ou sur les circuits imprimés
sans être électriquement relié à la terre. Manipuler les circuits imprimés en les tenant seulement par leurs bords. Les
décharges électrostatiques (ESD) peuvent endommager l'équipement, même si vous ne pouvez pas le sentir, le voir ou
l'entendre.
• Thumbscrews should be tightened with a tool after both initial installation and subsequent access to the panel.
• Les vis doivent être serrées avec un outil adapté après la première installation et l'accès postérieur au panneau.
NOTES:
• On a fiber optic I/O module as delivered from Extron, all transceiver modules are configured the same: either all
multimode or all singlemode. Multimode and singlemode fiber optic I/O modules can be mixed in a FOX3 Matrix
switcher, but ensure the proper transmission mode fiber cables are connected to the board.
• Typically, singlemode fiber has a yellow jacket and multimode cable has an orange or cyan jacket.
• For proper cooling and air flow, boards or blank panels should be installed in all locations during normal switcher
operations.
• The FOX3 Matrix Switcher components that are user-replaceable are hot-swappable. The switcher does not need to be
powered down to remove or replace a component.
Replace a module or card as follows:
1. Disconnect any connected cables.
2. Rotate the left and right captive panel screws to
completely loosen the screws (see figure 16 and
figure 17).
3. Gently pull on the captive panel screws to loosen the
module from the backplane.
4. Slide the module out of the chassis.
5.
Place the removed module on an anti-static surface or
in an anti-static container.
6. Align the replacement module with the left and right
chassis guides.
7.
Gently slide the replacement module into the enclosure.
Slide the module toward the front panel until it meets
resistance.
8. Gently seat the replacement module in the backplane.
9.
Use a screwdriver to tighten the left and right captive
panel screws to lock the replacement module in place.
14
Figure 16.
Replacing an I/O Board
Figure 17.
Replacing a Control Card
D IO
AU O N
R IX N SI
M AT PA
X3 EX
FO TE
D AN IO N
PA NS
EX
DI O AT
AU
P
D M O N
S R N SI
TP UT PA
OU L EX
DI O
AU R
L 3
S 4 R
TS R
IN PU 1 L
DI O L
AU R 2 R
L 3 L
4
R
1
L
2 R
L
N
LA
E
M OT
RE
LY 2
ro n M B -23
E xt SE RS
AS
N
FA Rx G
Tx
ND Align with Plastic Guides
GE
T LE
33 -40
UT PU
T/ O 25 -32
24
IN PU 17-
6 T
9-1 SE
1- 8 RE
Captive Panel Screw
D IO
AU O N
R IX N SI
M AT
PA
X3 EX
FO TE
D AN IO N
PA NS
EX
DI O AT
AU
P
D M O N
S N SI
TP UT R
OU EX PA
DI O L
AU R
L 3
S 4
TS R R
IN PU 1
DI O L L
2
AU R R
L 3 L
4 R
1 L
2 R
L
LA N
B LY
ro n
E xt EM
A SS
N
FA
D
G EN
T LE
PU 33 -4 0
UT
T/ O 25 -32
IN PU 4
17 -2
9- 16
1- 8
CO CO
Q Q xi xi
O O
P PR P PR
IPC IPC
N N
LA LA
N N
AV AV LA LA
TE TE
MO MO
RE RE
-2 32 -2 32
RS RS
G G
Rx Rx
Tx Tx
T T
SE SE
RE RE
Captive Panel Screw
RO RO L L
NT NT
CO CO
TR TR IX IX
MA MA
X3 X3
FO FO
L L
NT NT RO RO
IG IG SE SE T T
CO CO NF NF RE RE
