User Manual

Matrix Cat6

MU-IP1613 / 1624

MU-IP3213 / 3224

Matrix Cat6 KVM

MU-1602 / 1603 / 1604

MU-3202 / 3203 / 3204

UM-CV-751-MUKVM-Q218V2

dedicated KVM switch and rackmount screen technology

KVM

751

Need help?

Do you have a question about the MU-IP1613 and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberView MU-IP1613

Page 1 KVM switch and rackmount screen technology dedicated KVM switch and rackmount screen technology User Manual User Manual Matrix Cat6 Matrix Cat6 MU-IP1613 / 1624 MU-IP3213 / 3224 Matrix Cat6 KVM MU-1602 / 1603 / 1604 MU-3202 / 3203 / 3204 UM-CV-751-MUKVM-Q218V2...
Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
Page 4 Contents Contents < Part 1 > Matrix Cat6 < Part 1 > Matrix Cat6 MU-IP1613 MU-IP1624 MU-IP1613 MU-IP1624 MU-IP3213 MU-IP3224 MU-IP3213 MU-IP3224 Package contents Package contents KVM port & Cat6 dongle connection KVM port & Cat6 dongle connection IP, Remote & Local console connection IP, Remote &...
Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
Page 6 Part 1. Matrix Cat6 < 1.1 > Package Contents Matrix Cat6 IP KVM MU-IP1613 / MU-IP3213 MU-IP1624 / MU-IP3224 • MU-IP1613 or MU-IP3213 or MU-IP1624 or MU-IP3224 KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit •...
Page 7 < 1.2 > KVM port & Cat6 dongle connection Matrix Cat6 IP KVM DG-100P DG-100H DG-100SD DG-100S DG-100 DP-USB dongle HDMI-USB dongle DVI-USB dongle VGA-USB dongle VGA-PS/2 dongle Servers Servers DG-100P DG-100P CAT 5 / 6 cable CAT 5 / 6 cable max.
Page 8 < 1.3 > IP, Remote & Local console connection Matrix Cat6 IP KVM Receiver For remote console, max. cable length is subject to the resolution. Please refer to the tables below. IP Console Remote Console Frequency Frequency Max. Cat6 Cable Resolution Support Resolution Support ( Hz )
Page 9 How to use a receiver to connect a remote console Matrix Cat6 IP KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Remote Console Local computer...
Page 10 After the cable connection, please take the following steps to configure the IP KVM : 1. Download from the link: IPKVMsetup.exe www.austin-hughes.com/support/utilities/cyberview/IPKVMsetup.exe 2. Double click to configure the IP KVM by device setup as below. IPKVMsetup.exe 3. Click Refresh Device to search the connected IP KVM 4.
Page 11 < 1.5 > Important Preconfiguration for IP console Matrix Cat6 IP KVM You must complete the following tasks after the IP console setting is performed. ( 1 ) TARGET SERVER SETUP **Servers connected to KVM Resolution The IP KVM remote console recognizes several varieties of video display formats with resolutions up to 1600 x 1200 @60Hz.
Page 12 < 1.5 > Important Preconfiguration for IP console Matrix Cat6 IP KVM ( 2 ) REMOTE CLIENT COMPUTER SETUP The remote client computer must have a web browser ( such as Microsoft Internet Explorer, Mozilla Firefox, and Netscape Navigator ) and a Java Virtual Machine ( version 1.4 or higher ) installed. Enable Java on the web browser.
Page 13 Matrix Cat6 IP KVM Matrix Cat6 IP KVM 6) Click < Update > 6) Click < Update > After the firmware has been updated, IP KVM will reset automatically. After the firmware has been updated, IP KVM will reset automatically. After one minute, you will be redirected to the Login page and requested to login again.
Page 14 < 1.6 > KVM Cascade Matrix Cat6 IP KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.
Page 15 16: 9 - max. 1920 x 1080 16:10 - max. 1920 x 1200 ▀ IP Remote Console Number of IP console : 1 for MU-IP1613 / MU-IP3213 2 for MU-IP1624 / MU-IP3224 User management : 15-user login, 1 x active user Browser :...
Page 16 Part 2. Matrix Cat6 KVM < 2.1 > Package Contents Matrix Cat6 KVM MU-1602 / MU-3202 • MU-1602 or MU-3202 KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit • Power adapter w/ power cord ( for KVM ) x 1 •...
Page 17 Matrix Cat6 KVM MU-1602 Local Console Remote Console 1 Power Cascade MU-3202 MU-1603 Local Console Remote Console 1 Power Remote-2 Cascade MU-3203 MU-1604 Remote-3 Local Console Remote Console 1 Power Remote-2 Cascade MU-3204 P.12 UM-CV-751-MUKVM-Q218V2...
Page 18 < 2.2 > KVM port & Cat6 dongle connection Matrix Cat6 KVM DG-100P DG-100H DG-100SD DG-100S DG-100 DP-USB dongle HDMI-USB dongle DVI-USB dongle VGA-USB dongle VGA-PS/2 dongle Servers Servers DG-100P DG-100P CAT 5 / 6 cable CAT 5 / 6 cable max.
Page 19 < 2.3 > Local console & remote console connection Matrix Cat6 KVM For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Remote Console Frequency Max. Cat6 Cable Resolution Support ( Hz ) Length ( M ) 1920 x 1080 1920 x 1200...
Page 20 How to use a receiver to connect a remote console Matrix Cat6 KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Remote Console Local computer CE-6...
Page 21 < 2.4 > KVM Cascade Matrix Cat6 KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.
Page 22 < 2.5 > Specifications Matrix Cat6 KVM MU-1602 MU-1603 MU-1604 MU-3202 MU-3203 MU-3204 ▀ KVM Port Number of ports : 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable ▀...
Page 23 Part 3. Usage Matrix Cat6 KVM Usage 3.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch finally computer Front Panel - Port LED Indications 16 ports Bank no.
Page 24 3.2 Password rix Cat6 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...
Page 25 3.3 KVM OSD 3.3 KVM OSD Matrix Cat6 KVM Usage OSD Menu OSD Menu OSD operation OSD operation next to the system name The PC is powered on next to the system name The PC is powered on next to the system name The PC is selected next to the system name The PC is selected...
Page 26 3.4 KVM Hotkey & Remote Console Hotkey Matrix Cat6 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +...
