  • Page 1: User Manual

    KVM switch and rackmount screen technology User Manual Combo Cat6 2-console KVM U-IP802 / 1602 / 3202 Combo Cat6 2-console KVM U-802 / 1602 / 3202 Combo Cat6 KVM U-801 / 1601 / 3201 Designed and manufactured by Austin Hughes UM-CV-751-UKVM-Q116V2 www.austin-hughes.com...

  • Page 2: Legal Information

    Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part 1 > Combo Cat6 2-console KVM U-IP802 U-IP1602 U-IP3202 Package contents KVM port & Cat6 dongle connection IP & Local console connection IP console setting Important Preconfi guration for IP console P.5 - 7 KVM Cascade Specifi cations <...

  • Page 4: Before Installation

    Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.

  • Page 5: U-Ip802 U-Ip1602 U-Ip3202

    Part 1. Combo Cat6 < 1.1 > Package Contents Combo Cat6 IP KVM U-IP802 / U-IP1602 / U-IP1602 KVM unit • UIP-802 or UIP-1602 or UIP-3202 KVM unit x 1 • Mounting set w/ bracket & screws x 1 •...

  • Page 6: Kvm Port & Cat6 Dongle Connection

    < 1.2 > KVM port & Cat6 dongle connection Combo Cat6 IP KVM USB Servers DG-100SD DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers DG-100S DG-100 PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max.

  • Page 7: Ip & Local Console Connection

    < 1.3 > IP & Local console connection Combo Cat6 IP KVM Local console Network device hub or router CAT 5 / 6 cable max. 100m IP Console Frequency ( Hz ) Resolution Support 1600 x 1200 1280 x 1024 1024 x 768 60 / 70 / 75 UM-CV-751-UKVM-Q116V2...

  • Page 8: Ip Console Setting

    After the cable connection, please take the following steps to confi gure the IP KVM : 1. Download IPKVMsetup.exe from the link: www.austin-hughes.com/support/utilities/cyberview/IPKVMsetup.exe 2. Double click IPKVMsetup.exe to confi gure the IP KVM by device setup as below. 3. Click Refresh Device to search the connected IP KVM 4.

  • Page 9: Important Preconfi Guration For Ip Console

    < 1.5 > Important Preconfi guration for IP console Combo Cat6 IP KVM You must complete the following tasks after the IP console setting is performed. ( 1 ) TARGET SERVER SETUP **Servers connected to KVM Resolution The IP KVM remote console recognizes several varieties of video display formats with resolutions up to 1600 x 1200 @60Hz.
  • Page 10 < 1.5 > Important Preconfi guration for IP console Combo Cat6 IP KVM ( 2 ) REMOTE CLIENT COMPUTER SETUP The remote client computer must have a web browser ( such as Microsoft Internet Explorer, Mozilla Firefox, and Netscape Navigator ) and a Java Virtual Machine ( version 1.4 or higher ) installed. Enable Java on the web browser.
  • Page 11 Combo Cat6 IP KVM 6) Click < Update > After the firmware has been updated, IP KVM will reset automatically. After one minute, you will be redirected to the Login page and requested to login again. - Completed UM-CV-751-UKVM-Q116V2 www.austin-hughes.com...

  • Page 12: Kvm Cascade

    < 1.6 > KVM Cascade Combo Cat6 IP KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of U-801 / U-1601 / U-3201. When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.

  • Page 13: Specifi Cations

    < 1.7 > Specifi cations Combo Cat6 IP KVM U-IP802 U-IP1602 U-IP3202 KVM Port ▀ Number of ports : 8, 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via...

  • Page 14: Part 2. Combo Cat6 2-Console Kvm

    Part 2. Combo Cat6 2-console KVM < 2.1 > Package Contents Combo Cat6 2-console KVM U-802 / U-1602 / U-3202 • U-802 or U-1602 or U-3202 KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit •...

  • Page 15: Kvm Port & Cat6 Dongle Connection

    < 2.2 > KVM port & Cat6 dongle connection Combo Cat6 2-console KVM USB Servers DG-100SD DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers DG-100S DG-100 PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max.

  • Page 16: Remote & Local Console Connection

    < 2.3 > Remote & Local console connection Combo Cat6 2-console KVM Local console Remote Cat6 Console Remote Receiver USB console CAT 5 / 6 cable max. 150m Remote Console Frequency ( Hz ) Resolution Support 1600 x 1200 1280 x 1024 1024 x 768 60 / 70 / 75 P.12...
  • Page 17 How to use a receiver to connect a remote console Combo Cat6 2-console KVM Receiver Local Computer Monitor Remote I/O Front Power Rear Local Remote Mouse Button Button KVM switch The receiver provides a hotkey function for remote console. Please refer to P.23 Monitor Remote Console...

  • Page 18: Kvm Cascade

    < 2.4 > KVM Cascade Combo Cat6 2-console KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of U-801 / U-1601 / U-3201. When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.

  • Page 19: Specifi Cations

    < 2.5 > Specifi cations Combo Cat6 2-console KVM U-802 U-1602 U-3202 KVM Port ▀ Number of ports : 8, 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console ▀...

  • Page 20: Part 3 > Combo Cat6 Kvm

    Part 3. Combo Cat6 KVM < 3.1 > Package Contents Combo Cat6 KVM U-801 / U-1601 / U-3201 KVM unit • U-801 or U-1601 or U-3201 KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 U-801 Local Console...

  • Page 21: Kvm Port & Cat6 Dongle Connection

    < 3.2 > KVM port & Cat6 dongle connection Combo Cat6 KVM USB Servers DG-100SD DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers DG-100S DG-100 PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max.

  • Page 22: Kvm Cascade

    < 3.3 > KVM Cascade Combo Cat6 KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of U-801 / U-1601 / U-3201. When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.

  • Page 23: Specifi Cations

    < 3.4 > Specifi cations Combo Cat6 KVM U-801 U-1601 U-3201 KVM Port ▀ Number of ports : 8, 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console ▀...

  • Page 24: Part 4. Usage

    Part 4. Usage Combo Cat6 KVM Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no.

  • Page 25: Password

    4.2 Password Combo Cat6 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...

  • Page 26: Kvm Osd

    4.3 KVM OSD Combo Cat6 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port...

  • Page 27: Kvm Hotkey & Remote Console Hotkey

    4.4 KVM Hotkey & Remote Console Hotkey Combo Cat6 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +...
  • Page 28 4.5 Options : DC Power Combo Cat6 KVM Usage Model 110 ~ 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 50 mA...
