- Page 1 KVM switch and rackmount screen technology User Manual USB Hub DB-15 2-console KVM IP-802H USB Hub DB-15 2-console KVM CV-802H USB Hub DB-15 KVM CV-801H Designed and manufactured by Austin Hughes UM-CV-751-USBKVM-Q221V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, December 2021 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > USB Hub DB-15 2-console KVM IP-802H Package Contents KVM port connection IP & Local console connection IP console setting Important Preconfi guration for IP console P.5 - 7 Built-in USB Hub Usage & Connection Specifi cations <... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Part 1 > Usb Hub
USB Hub DB-15 IP KVM < 1.1 > Package Contents IP-802H KVM unit • IP-802H KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power adapter w/ power cord ( for KVM ) x 1 IP-802H... -
Page 6: Kvm Port Connection
< 1.2 > KVM port connection USB Hub DB-15 IP KVM CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q221V1... -
Page 7: Ip & Local Console Connection
< 1.3 > IP & Local console connection USB Hub DB-15 IP KVM Network device hub or router CAT 5 / 6 cable IP Console Frequency Resolution Support ( Hz ) 1600 x 1200 1280 x 1024 1024 x 768 60 / 70 / 75 UM-CV-751-USBKVM-Q221V1 www.austin-hughes.com... -
Page 8: Ip Console Setting
9. Change the desired IP address / Subnet mask / Gateway, then click Setup Device to confi rm the setting to IP KVM 10. The default address is as below:-- ■ The single IP KVM model, such as IP-802H - http://192.168.1.22 11. Open Internet Explorer ( I.E. ), version 6.0 or above 12. -
Page 9: Important Preconfi Guration For Ip Console
< 1.5 > Important Preconfi guration for IP console USB Hub DB-15 IP KVM You must complete the following tasks after the IP console setting is performed. ( 1 ) TARGET SERVER SETUP **Servers connected to KVM Resolution The IP KVM remote console recognizes several varieties of video display formats with resolutions up to 1600 x 1200 @60Hz. - Page 10 < 1.5 > Important Preconfi guration for IP console USB Hub DB-15 IP KVM USB Hub DB-15 IP KVM ( 2 ) REMOTE CLIENT COMPUTER SETUP The remote client computer must have a web browser ( such as Microsoft Internet Explorer, Mozilla Firefox, and Netscape Navigator ) and a Java Virtual Machine ( version 1.4 or higher ) installed.
- Page 11 USB Hub DB-15 IP KVM 6) Click < Update > After the firmware has been updated, IP KVM will reset automatically. After one minute, you will be redirected to the Login page and requested to login again. - Completed UM-CV-751-USBKVM-Q221V1 www.austin-hughes.com...
-
Page 12: Built-In Usb Hub Usage & Connection
< 1.6 > Built-in USB Hub Usage & Connection USB Hub DB-15 IP KVM 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q221V1 www.austin-hughes.com... -
Page 13: Specifi Cations
< 1.7 > Specifi cations USB Hub DB-15 IP KVM IP-802H KVM Port ▀ Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet Local Console ▀... -
Page 14: Usb Hub 2-Console Kvm
< Part 2 > USB Hub DB-15 2-console KVM USB Hub 2-console KVM < 2.1 > Package Contents CV-802H • CV-802H KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit • Power adapter w/ power cord ( for KVM ) x 1 •... -
Page 15: Kvm Port Connection
< 2.2 > KVM port connection USB Hub 2-console KVM CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q221V1... -
Page 16: Remote & Local Console Connection
< 2.3 > Remote & Local console connection USB Hub 2-console KVM oc l console e o e onsole e o e USB console For remote console, max. cable length is ecei e subject to the resolution. Please refer to the tables below. Remote Console Frequency Max. - Page 17 How to use a receiver to connect a remote console USB Hub 2-console KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.23 Remote Console Local computer...
-
Page 18: Built-In Usb Hub Usage & Connection
< 2.4 > Built-in USB Hub Usage & Connection USB Hub 2-console KVM 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q221V1 P.14 P.14 www.austin-hughes.com... -
Page 19: Specifi Cations
< 2.5 > Specifi cations USB Hub 2-console KVM CV-802H KVM Port ▀ Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet Local Console ▀ Graphic connector : 1 x DB-15 Input device : 2 x USB type A for keyboard &... -
Page 20: Usb Hub Db-15 Kvm
< Part 3 > USB Hub DB-15 KVM USB Hub DB-15 KVM < 3.1 > Package Contents CV-801H KVM unit • CV-801H KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 CV-801H Power Local Console... -
Page 21: Kvm Port Connection
< 3.2 > KVM port connection USB Hub DB-15 KVM CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q221V1... -
Page 22: Built-In Usb Hub Usage & Connection
< 3.3 > Built-in USB Hub Usage & Connection USB Hub DB-15 KVM 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q221V1 P.18 P.18 www.austin-hughes.com... -
Page 23: Specifi Cations
< 3.4 > Specifi cations USB Hub DB-15 KVM CV-801H ▀ KVM Port Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet ▀ Local Console Graphic connector : 1 x DB-15 Input device : 2 x USB type A for keyboard &... -
Page 24: Usage
< Part 4 > Usage USB Hub DB-15 KVM Usage < 4.1 > KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no. -
Page 25: Password
< 4.2 > Password USB Hub DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 26: Kvm Osd
< 4.3 > KVM OSD USB Hub DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter... -
Page 27: Kvm Hotkey & Remote Console Hotkey
< 4.4 > KVM Hotkey & Remote Console Hotkey USB Hub DB-15 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port... - Page 28 < 4.5 > Options : DC Power USB Hub DB-15 KVM Usage Model 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 50 mA...
