Classic Exhibits VISIONARY DESIGNS MOD-1711 Setup Instructions

© 2022
Order #XXXXX
SEG Graphic Installation
Corner A Corner B
Corner D
Corner C
Step 1
It is important to first insert
Insert corner A. Turn edge of
graphic into each alternate
graphic so silicon welt is
corner, then to the sides of
perpendicular to face of
the frame. If this is not done,
graphic. Insert narrow side
graphic will not fit into the
of welt with fabric to outside
frame correctly.
into the channel. Repeat for
other side of this corner.
Step 2 Step 3
Repeat Step 1 for opposite Once all corners are inserted,
corner C, then insert corner press one silicon edge into
B, followed by corner D, to channel from corners and
complete the installation of work toward the center.
the corners. Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab. Gently pull up on
the tab to remove the fabric.
MOD-1711 Monitor Kiosk
Steps:
1) Attach Monitor to Kiosk base, using bolts.
2) Connect power cords to Supernova lights.
3) Apply SEG graphic to front frame of Kiosk.
Light to Light Attachment Light to Transformer Attachment
Male
Lights
+
+
Power
-
- Transformer
96W / 4 Amp / 24V
Maximum of 7 lights per chain / 7 lights per Transformer
p h ic
S E G G ra
Transformer
+
-
Female
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com
REV 9/2022
FRONT VIEW
BACK VIEW
When assembled
