LW Scientific Advanced Scope OEM-SAF3 Specifications

Advanced Scope
Construction
Heavy cast alloy
Acid and reagent resistant finish
All metal gearing
Head
Standard monocular head
Bearing mounted, rotates 360°
10X/18 wide field eyepiece
Locked-in eyepiece with pointer installed
Teaching head available
Objectives
Four position nosepiece
DIN Achromatic 4X, 10X, 40XR (retractable)
Optional 100x oil objective
Parfocal and parcentric
Color coded
Stage
Pre-drilled and tapped for optional mechanical stage
Spring-loaded slide clips included
Stage size: 110mm x 110mm
Adjustment Controls
Coaxial coarse and fine focus
Adjustable stage stop
Illumination
NA 1.25 ABBE condenser
Iris Diaphragm
5w fluorescent
Input 110V (220V optional)
Accessories Included
Dust cover, blue and green filters, two fuses, spare
bulb, manual and warranty card
Warranty
One year on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 14" (356mm)
Length: 7.0" (178mm)
Width: 5.25" (134mm)
Weight: 6.1 lbs. (2.8kg)
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
•
Iris Diaphragm
•
Optional 100x objective
•
Coaxial Focus Knobs
For the teacher that wants more than just the
basic microscope for his classroom this
advanced model is an excellent choice. The
1.25 ABBE condenser allows the addition of a
100x oil immersion objective. The iris
diaphragm allows precision adjustments to the
cool fluorescent light.
P a t r # H e a
O E M - S A F 3 M o n
O E M - S A F 4 M o n
*To include an add-on mechanical stage, add an "M" to the part number.
- email: sales@lwscientific.com
d O b j e c t v i e s l I u l m n i a
o c 4 - 1 0 - 4 0 X F u l o e r s c
o c 4 - 1 0 - 4 0 - 1 0 0 X F u l o e r s c
t o i n
e n t
e n t
