Barco F90 series Quick Start Manual

F90-series Quick Start Guide
Projector Main Components and interface Projector Main Components and interface
1
1 2
LED status light
1
2 Adjustable feet.
3 Projector lens.
4
Lens holder.
5 IR receiver: For receiving remote control signals
6
LCD touchscreen panel.
7
Keypad: Used for local operations on the projector.
8
Connector panel: Control and communication interfaces for the projector.
Front USB and Triggerboard.
9
Printed on FSC certi ed paper (www.fsc.org)
1
3
1 2
5
4
601-0383-01
General
5
7
6
1 2
1 9
WARNING!
Class 1 Laser RG2 Product.
For North America, Class 3R up to TR 2.33
This Projector may become RG3.
Refer to user manual before operating
Do not stare into beam. This projector
has class 4 laser cluster. Do not attempt
to disassemble or modify this projector.
LED Status Light LED Status Light
1
Red light indicates a failure.
Contact service representative.
