Kitchen Island
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
M.
Base
1 pc.
P.
Post
1 pc.
Hardware List
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Also need the parts in cartons 88 5076 942 and 88 5077 941 or 88 5077 944
Tools required for assembly : Phillips screwdriver, Drill, 3/8" Drill Bit, Level
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
Q.
Post
1 pc.
Cam Lock
8 pcs.(+2 extra)
Cam Lock Screw
8 pcs.(+1 extra)
servicedesk@homestyles-furniture.com
N.
Side Panel
2 pcs.
R.
Post
1 pc.
Adjustable Pin
32 pcs. (+1 extra)
M x 6 35
Head Cap Bolt
22 pcs. (+1 extra)
M4x25
Machine Screw
2 pcs.
M3.5x19
Wood Screw
9 pcs. (+1 extra)
O.
Back Panel
2 pcs.
S.
Post
1 pc.
Knob
2 pcs.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles 88 5076 943
Summary of Contents for Home Styles 88 5076 943
- Page 1 1 pc. Also need the parts in cartons 88 5076 942 and 88 5077 941 or 88 5077 944 Tools required for assembly : Phillips screwdriver, Drill, 3/8” Drill Bit, Level Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319 servicedesk@homestyles-furniture.com...
- Page 2 Assembly Instructions 2/5 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Cam Locks in the future. * Use a soft cloth between these parts and the floor.
- Page 3 Assembly Instructions 3/5 STEP 3 Remove the drawers from Upper Unit (C). Head Cap Bolt Figure 3 STEP 4 Cam Lock Attach Upper Unit (C) to Top (A) with Head Cap Bolts and Cam Locks. (See Figures 3 and 4) Figure 4 Head Cap Bolt STEP 5...
- Page 4 Assembly Instructions 4/5 Head Cap Bolt Cam Lock STEP 6 Attach Post (P) and Middle Panel (G) to unit with Head Cap Bolts. Attach Front Rail (D) to unit with Cam Lock. Attach Post (R) to unit with Head Cap Bolts and Cam Lock. STEP 7 Slide Side...
- Page 5 Assembly Instructions 5/5 Head Cap Bolt STEP 8 Attach Wood Supports (J) to unit with Head Cap Bolts. Attach top unit to base unit with Head Cap Bolts. Figure 5 Figure 6 Figure 7 Adjustable Pin STEP 9 Insert the Adjustable Pins into the side and middle panels at...
