2.11 MOUNTING THE BOILER - EXTERNAL

1
1. Fit the flue turret. Refer to Section 2.14.
2. Ensure the plastic plugs are rmoved from both the CH and DHW connections before mounting the boiler.
Note: Boiler may contain residual water.
3.
Lift the boiler onto the wall mounting plate (refer to the Introduction Section for safe handling advice), locating it over the two
tabs.
Note: Install service connections at this point.
Installation and Servicing
SECTION 2 - INSTALLATION
Ensure the
flue turret is
perpendicular to the
front of the boiler.
3
