Installation
The XPMC-6710 can be installed in carrier board with an available universal PMC site. Refer
to the carrier board manufacturer documentation for the installation of PMCs. Below is an
illustration for a typical installation of a PMC.
Installation Procedure:
Document Number: 646710
1. Ensure that all user configurable jumpers and switches are set as desired on the
XPMC-6710. See Figure 1-3 on page 29 for the switch configurations.
2. Install the standoffs on the board as shown in Figure 1-2 on page 28.
3. Remove the blank covering the PMC site from the carrier (if applicable). Insert the PMC
through the front panel
4. Press firmly on the board until the four connector are fully mated.
5. With the solder side facing up on the carrier, install the screws according to the drawing
in Figure 1-2 on page 28.
6. Connect all peripherals to the front panel. See Figure 1-1 on page 25 for location and
illustration of the front panel connectors.
7. Installation is complete, power up the board
1
Installation
27
