Specifications

The following table is the XPMC-6710 Specifications, showing the recommended operating
conditions for XPMC-6710.
Condition
Compliance
Air Flow
Pay load power
Operating Temperature:
Storage Temperature
Relative Humidity
Operating Altitude
Non Operating Altitude
Shock
Vibration
MTBF
Weight
*Minimum Battery Voltage
NOTE:
Xembedded for replacement of the Battery. Contact Your Sales representative for a Return
Material Authorization (RMA) prior to returning the XPMC-6710. You can reach Xembedded
at:
Tel: (702) 896-3337 or Email us at: support@Xembedded.com

Safety:

Design to meet or exceed UL 60950 3rd Ed.; CSA C22.2 No.60950-00; EN60950; IEC
60950-a

EMC;

Design to meet or exceed FCC 47 CFR Part 15, Class B; CE Mark to EN55022/EN55024
Warranty: 2 year limited
Document Number: 646710
Table 2 XPMC-6710 Product Specification
IEEE 1386.1 (CMC Standard), VITA 32 (PrPMC Standard)
200 LFM
20 Watt Max at 1.75GHz
0° to +55° C
-40°to +85° C
5% to 95% (non condensing)
15000 ft.
51000 ft.
30G each axis
.05G RMS, 20-2000Hz random (Operating): 6Gs RMS,
MIL Spec 217-F @ 105,000 Hrs.
4.3 Oz.
+2.2V
*The Battery is not field replaceable and the XPMC-6710 MUST be returned to
Recommendation
Overview
