XPMC-6710 Reference Manual
Sources of Reset
There are several potential sources to rest the XPMC-6710:
• Power on reset
• PCI reset from the Carrier module
• COP Header if JTAG is used
• Tsi109 GPIO11
• SW1 on the back of the board during debugging
The XPMC-6710 also outputs the *RESETOUT on Pin 60 of the P2 connector during power
up reset or reset from the Tsi109. The *RESETOUT signal is independent of the PMC PCI
reset.
24
Document Number: 646710
