UG-548
EVAL-ADM1075-ISOZ
Table 7. Connector Functions
Connector Description
J1 8-way connector; use a Micro-MaTch ribbon cable to connect to an
J2 10-way connector; use a
Table 8. Switch Functions
Switch Description
SHDN2 Toggle switch to shut down hot swap. Right = hot swap enabled; left = hot swap disabled.
SHDN Push-button switch to generate a shutdown. This push-button can be used to clear faults. Note that SHDN has a retry
counter capable of counting up to seven shutdown events. After seven shutdown events, GPO2 goes active low, and
then a restart or clear via a PMBus is required to enable the hot swap again.
DELATCH Push-button switch to clear a latch event after seven shutdown events.
SPARE Push-button switch connected to GPO1_TP.
Table 9. LED Functions
LED Description
PWRGD PWRGD, active low; green.
LATCH LATCH, active low; red.
ISO 5 V power supply from USB-SDP-CABLEZ, active high; blue.
Table 10. On-Board ICs
IC Description
U1 ADuM5404, quad-channel isolator with integrated dc-to-dc converter.
U2 ADuM1250 dual I
USB-SDP-CABLEZ dongle to connect to a PC.
2
C isolator.
Rev. A | Page 8 of 16
