- Page 1 888-230-2225 help@manhattancomfort.com Gramercy Wardrobe...
-
Page 2: Included In The Package
23 - Smaller Aluminum Hanger Bar = 01 piece 11 - Top Panel = 01 piece 24 - Larger Aluminum Hanger Bar = 03 pieces 12 - Smaller Crossbar = 02 pieces 25 - Handle = 06 pieces 13 - Larger Crossbar = 02 pieces Gramercy 02/12 wardrobe... - Page 3 P = 18x Tools needed Philips screw driver Screw driver (not included) 11 lb 11 lb Front view 11 lb 15.4 lb All the hanger 11 lb bars 15.4 lb. 11 lb 11 lb 11 lb Rear view Gramercy 03/12 wardrobe...
- Page 4 (C ). Using the hardware (J) and the hardware (E) connect the part (18) onto the part (03) and the part (19) onto the part (04). *Observe the right position of the parts (18) and (19). Gramercy 04/12 wardrobe...
- Page 5 Connect the part (12) onto the part (13) with the hardwares (F + G). Fix the hardware (H) onto the part (13) with the hardware (C). Step 04 Connect the part (01) onto the part (12) with the hardware (B). Gramercy 05/12 wardrobe...
- Page 6 Connect the part (05) onto the parts (01) and (13) with the hardware (B + L). Apply the hardware (O) on the hardware (L). Connect the parts (16) and (17) onto the parts (04) and (05) with the hardware (B). Gramercy 06/12 wardrobe...
- Page 7 Apply the hardware (O) on the hardware (G). Connect the part (15) onto the part (14) with the hardware (F + G). Apply the hardware (O) on the hardware (G). Connect the part (15) onto the part (02) with the hardware (B). Gramercy 07/12 wardrobe...
- Page 8 Connect the part (11) onto the 03 04 parts (03) and (04) with the hardware (F + G). Apply the hardware (O) on the hardware (G) and (L). Step 03 Step 10 Connect the parts (23) and (24) into the hardware (N). Gramercy 08/12 wardrobe...
- Page 9 (M) and (I). Step 03 Step 12 Connect the parts (07), (08) and (09) with the hardware (B). Apply the part (10) in the groove of the parts (07) and (08) until the groove of the part (09). Gramercy 09/12 wardrobe...
- Page 10 Connect the parts (07), (08) and (06) using the hardware (F + G). Apply the hardware (O) on the hardware (G). Step 03 Step 14 Use the hardware (C) with the hardware (K) as shown on detail. Gramercy 10/12 wardrobe...
- Page 11 (03) and (04). Step 16 Fix the hardware (P) onto the part (20) with the hardware (A). Connect the part (25) onto the part (20) with the hardware (D). Gramercy 11/12 wardrobe...
- Page 12 Step 17 Connect the part (20) onto the parts (02), (03), (04) and (05) with the hardware (A). After adjusting the Hinge Adjust Screw lock with the bolts (A). Adjust Screw Adjust Screw Gramercy 12/12 wardrobe...
