Getting Started; Parts List; Preparation - THORLABS PDA8A2 Abbreviated Operation Manual

PDA8A2

2 Getting Started

2.1 Parts List

Please inspect the shipping container for damage. Please do not cut through the cardboard.
You might need the box for storage or for returns.
If the shipping container seems to be damaged, keep it until you have inspected the contents
and you have inspected the PDA8A2 mechanically and electrically.
Verify that you have received the following items within the package:
1. PDA8A2 Amplified Photodetector
2. Plastic Cover Cap
Retaining Ring
3. LDS12B Power Supply (±12V, 0.2A), 100 VAC, 120 VAC or 230 VAC Line Voltage
4. Quick Reference

2.2 Preparation

Carefully unpack the unit and accessories. If any damage is noticed, do not use the unit.
Contact Thorlabs
13
Note
Prior to operation, please check if the indicated line voltage range on the power supply matches
with your local mains voltage! Adjust the power supply accordingly to 100 VAC, 120 VAC or
230 VAC.
Note
If you prefer to use your own power supply, please ask
connector cable.
2
(Item # SM1EC2B) on
and have us replace the defective unit.
SM1T1-SM1 Coupler
Thorlabs
with an SM1RR-SM1
for an appropriate power
13
© 2022 Thorlabs GmbH
