Appendix B: Exciter Specifications
Physical and Mechanical
Dimensions: 245mm X 200mm X 60mm (9.6in x 7.9in x 2.4in)
•
Weight: 865g (31oz)
•
Housing: Polycarbonate and ABS
•
Coverage
Adjustable coverage range between 1.5m (4.9 ft.) and 6.5m (21.3 ft.) by
•
intervals of 0.5 m (1.6 ft.)
LF Channel
125 KHz
•
Field intensity limits: 37.3 dBµA/m at 10 m (ETSI)
•
Propagation limits: 21.8 dBµV/m at 300 m (FCC)
•
Modulation: ASK
•
Network Interface
Ethernet (RJ-45)
•
Power
Input voltage: 24-48 VDC
•
PoE (802.3af) 48 VDC
•
Maximum power consumption: 6W
•
Maximum power consumption of External LF Antenna: 5W
•
Environmental
Operating temperature: 0 to 50 °C (32°F to 122°F)
•
Humidity: 0 to 95%, non-condensing
•
Certifications
EMC Certifications
•
US standard: FCC part 15 sub part B
•
European standard: ETSI 300.328, 300.330, ETSI 301.489
•
Safety Certifications
•
US – cTUVus: UL 60950-1; -22
•
Europe – CE mark: EN 60950-1; -22
•
