Overview

The Stanley PAC iEVO Fingerprint Reader series of advanced fingerprint readers elevate biometrics recognition from limited use to universal acceptance.
When restricting access, a fingerprint is a one-of-a-kind solution that cannot be guessed, forgotten, stolen, shared or re-created.
The readers utilize Multispectral Imaging, a technology that has a proven track record involving millions of users and one that always works in real world
conditions. A 'hidden' internal image of a fingerprint exists far below the surface of the skin. The readers simultaneously capture an image of both the
surface and subsurface 'internal fingerprint' to capture clear, clean images every time - even when surface features are absent or hard to distinguish due to
age, dirt, finger pressure and skin or environmental conditions. The sensor is also able to identify whether the fingerprint is genuine or a fake/spoof.
The Ultimate Reader can be installed externally, it is built to ensure long lasting durability regardless of weather conditions, accidental damage or physical
attack. The reader is wired to a Control Board that is installed on the secure side of the door, this leaves nothing at the reader to compromise door
security.
Users are enrolled within the Stanley PAC software, eliminating the need for a separate application. The finger to be enrolled (up to ten) is selected, and
after it has been added the fingerprint data is sent to all the other PAC iEvo readers via its LAN connection. The Stanley PAC software stores the
fingerprint against the cardholders record, confirms a presented fingerprint and passes the access authorized command to the PAC 512 Access Controller,
which opens the door.

Key Features

Compatible with all Stanley PAC Access Software Editions
Enables high throughput, identification in < 1 second
Maintains performance in rain, cold, dry, hot environments bright sunlight ot dark
conditions. Even when the finger is covered with Vaseline or wearing a Latex glove.
Images surface and subsurface fingerprint features using patented multispectral
imaging technology
The Control Board is mounted in environmentally protected secure side of the door
High durability glass platen with no coatings that wear out
Standard liveness detection to insure only genuine fingers can be matched
Operates across wide ranges of temperature, relative humidity, and ambient light
PAC Format support fpor Stanley PAC512-series Door Controllers
enables easy installation with low cost 22AWG Unshielded 4-conductor cable
Suitable for indoor and outdoor use (Micro - Indoor only)
Requires minimal maintenance
|
PAC iEVO Fingerprint Reader Series
MICRO
Mullion Mountable
ULTIM TE
Internal or External Use
