Parade Recessed
LB 2 / LB 3
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Inrush current
Corrente di spunto
Power factor
Fattore di potenza
Electrical class
Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Dimensions / Dimensioni
Parade LB 2
Parade LB 3
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
551178 Rev. 06
Date: 22/03/2024
Parade LB 2 Recessed
AL5280
0.13A@230V /27W
6.9 Kg ( 15.2 Lb )
680
26 3/4"
984
38 3/4"
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
120-277VAC / 50-60Hz
<200mA²s @ 230V/50Hz
cos.φ= 0.94
I
-20°C to +45°C ( -4°F to 113°F )
IP67
IK10
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
Parade LB 3 Recessed
AL5285
0.2A@230V / 40W
9.5 Kg ( 21 Lb )
84mm
3 1/4"
page 1 of 4
Advertisement
Related Manuals for Griven Parade LB 2 Recessed
Summary of Contents for Griven Parade LB 2 Recessed
- Page 1 3 1/4" 26 3/4" Parade LB 3 38 3/4" page 1 of 4 © Copyright Griven 2020 - GRIVEN S.r.l. is continuously Griven S.r.l. - Via Bulgaria, 16 Tel. +39.0376.779483 developing and improving all its products. E-mail: sales@griven.com 46042 Castel Goffredo We reserve the right to change specifications without...
- Page 2 Important notices - Avvisi importanti - This product must be installed in accordance with applicable national and local - Questo prodotto deve essere installato secondo le normative locali, da personale electrical and construction codes by a person familiar with the construction and specializzato.
- Page 3 Connection - Connessione “M” cable type ( Hybrid cable without connectors) Brown/Marrone=L (Line/Fase) Blue/Blu=N (Neutral/Neutro) Yellow/Green=GND Verde/Giallo=Terra Grey/Grigio= DALI + Black/Nero= DALI - Brown/Marrone=L (Line/Fase) Blue/Blu=N (Neutral/Neutro) Yellow/Green=GND Verde/Giallo=Terra Grey/Grigio= DALI + Black/Nero= DALI - Note: in absence of DALI signal the LEDs will remain ON. Nota: In assenza di segnale DALI i LED rimarranno accesi.
- Page 4 Note: Allowed operation only between sunset and sunrise Nota: Accensione dell’apparecchio ammessa soltanto tra gli orari di tramonto e alba page 4 of 4 © Copyright Griven 2020 - GRIVEN S.r.l. is continuously Griven S.r.l. - Via Bulgaria, 16 Tel. +39.0376.779483 developing and improving all its products.
