- Page 5 1. Align the bolt set (#A) to the two bottom holes along the upper front and back side rails (#5,6) and the upper HB/FB (#2) as shown to the left. Then secure using the Allen wrench. 2. Insert a long screw bolt (#C) into the top holes along the upper HB/FB (#2).
- Page 6 Insert a metal dowel (#D) into the holes along the top of the lower HB/FB (#1). Then with the help of another person, carefully place the upper bed onto the lower bed. Align the ladder (#8) to the holes along the upper front side rail (#5) and the lower front side rail (#3).
- Page 7 Place the slats (#7) onto the upper and lower beds. Insert a long screw (#E) into the ends of each slat, then secure using a Phillips screwdriver. Align the ends of the drawer back panel (#12) to the holes along the sides of the drawer side panels (#10).
- Page 8 Place the drawer front panel (#9) onto the front side of the drawer. Slide the drawer bottom panel (#11) into the ridges along the side panels. Insert 2 short screws (#F) to the holes along each side of the drawers. Secure using a Phillips screwdriver.
- Page 9 Insert drawers.
