For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 10
(Included)
(Not Included)
Rev: 18-06-27
Advertisement
Related Manuals for Furniture of America CM-BK633TF
Summary of Contents for Furniture of America CM-BK633TF
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #9 x 2pcs Upper End Guardrail Back Guardrail #2 x 1pc #10 x 2pcs Upper End Guardrail Front Guardrail #3 x 1pc...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #17 x 1Set #19 x 3pcs Full Slat Kit (13pcs) Support Leg 300x30x30mm #18 x 1pc Center Support Rail #A x 16pcs #F x 7pcs...
- Page 5 Exploded View Insert barrel nuts (#B) to the side holes of the lower side rails (#5,6). Align lower side rails (#5,6) to the holes of the lower end guardrails (#3,4), then secure by tightening bolts (#A) onto barrel nuts (#B). #A x 8pcs #B x 8pcs Page 5 of 10...
- Page 6 1) Insert dowels (#J) to guardrails (#9,10), then insert barrel nuts (#B) to upper side rails (#7,8). 2) Align guardrails (#9,10) and upper side rails (#7,8) to the upper end #A x 8pcs guardrails (#1,2), then secure with #B x 8pcs screws (#H) and bolts (#A).
- Page 7 Insert metal dowels (#E) to top holes of the lower guardrails (#3,4), then carefully place upper bunk bed on top of lower bunk bed. #E x 4pcs Align ladder rungs (#15) to the ladder rails (#13,14), then secure by using screws (#G). #G x 8pcs Page 7 of 10...
- Page 8 Align ladder to the bunk bed, then secure by using bolts (#F). #F x 4pcs Align support legs (#19) to center support rail (#18), then secure by using screws (#G). Adjust levelers of the support legs (#19) according to ground level.
- Page 9 Align slats (#11,17) to the bunk bed, then secure by using screws (#D). #D x 56pcs ASSEMBLY IS COMPLETED Page 9 of 10...
- Page 10 Page 10 of 10...
